RGBlink VSP 198CVS User Manual page 84

5. Communication Software Control Guide
How to Connect Windows Control Program by LAN Interface
Then press <Enter> button, the IP address (the red circle) will display on
the computer: 192.168.0.132 ;
The third step: Equipment IP address :192.168.0.100.
The fourth step: the two IP address are in the same band, i.e.192.168.0.XXX, the
If so, the communication connection can be built by line CAT5.
Note
VSP 198CVS
Computer IP address :192.168.0.132.
fourth section numbers (XXX) will not repeat previous.
If computer IP address and equipment IP
address are not in same band, For example, the
computer IP address is 218.032.010.201；We
need to revise the computer IP address to
192.168.0.xxx.
Open network connections, right click on
properties, Select Internet protocol (TCP/IP),then
User Manual 84
