2. Hardware Orientation
VSP 198CVS Back Panel
Used to connect the windows control program or device upgrade.

10. RS232 Interface

Used to connect the windows control program or device upgrade.

INPUT Interface

1) 2 CVBS inputs by BNC interfaces, (CV2 is CV module).
2) 2 VGA input by DB15 interface,(VGA2 is CV module).
3) 1 HDMI-A interface, can be compatible with HDMI inputs.
4) 1 DVI-I interface, can be compatible with HDMI, and support loop
through output for cascade or preview.
5) 3G SDI input (SDI module), and support loop through output for
cascade or preview.
3：CVBS Input
CVBS input, input standard video signal from players, cameras etc.,
supported resolution 480i and 576i via BNC. Supported standards include:
PAL, NTSC and SECAM.
4：VGA Input
VGA interface, input the video signal from HD player and computer, etc.
Compatible with YPbPr via the DB15 interface.
5：SDI Input
SDI input, input video signal from HD camera and radio processing
equipment, connect interface 5 via 75 ohms impedance BNC port.
6：SDI Loop Out
SDI loop output, connect the SDI input of the next VSP 198CVS for
VSP 198CVS
Note
3 and 4 input interface is option CV module .
Note
5 and 6 input interface is S option module .
User Manual 27
