Disconnecting Invited Participants; Invite Mode Exit - Polycom MGC-25 Release Notes

Table 5: Invite Dial String Format
Endpoint DTMF
Network Type Code
ISDN endpoint *36
MPI endpoint *37
SIP endpoint *38
Video Invite can be used in Video Conferences to which an Invite-enabled IVR Service is
assigned. Video Invite is enabled for the conference in the Properties -Settings dialog box
as for Audio Only and H.323 participants.

Disconnecting Invited Participants

To disconnect the last invited video participant (and not the last dial in participant), enter
the DTMF code #35, for all invitee types. Each time you enter #35, the system disconnects
the most recent invited participant.

Invite Mode Exit

The system automatically exists the video invite mode and returns the inviter to the
ongoing conference when :
A dial tone is heard, but no DTMF code is pressed within 5 seconds
•
When a DTMF code is activated but no number is entered within 10 seconds
•
• The pound (#) key is pressed directly after the DTMF code (i.e. *36#)
• A wrong number is dialed or the pound (#) key is not pressed at the end of the dialed
number
• No MCU recources. In such a case an error tone is heard.
Dial String Format
The participant dials *36 followed by the ISDN number
(i.e. 9925100) and pound key.
For example:
*36<dialtone->99251000#
The participant dials *37 followed by the service
number (MPI number), astrisks (*), and pound key.
For example:
*37<dialtone>5000*12345678#
The participant (inviter) dials *38, followed by the
E.164 alias or IP address and pound key.
For example:
• E.164 Alias - *35<dialtone>1141#
Note: The User Name (E.164 prefix) must be in a
numeric format and the domain name is the IP
Service SIP server domain name.
• The endpoint address dial string, substitute
periods (.) with an asterisk (*). -
*35172*22*176*11#
Version 9.0 Detailed Description - Video
21
