SmartNode 5400 Getting Started Guide

Introduction

This section provides information on the cables used to connect the SmartNode and the interface cards to the
existing network infrastructure and to third party products.

Console

The SmartNode can be connected to a serial terminal over its serial console port, as depicted in
CAUTION
Serial Terminal
Note
See section
Introduction
The interconnecting cables shall be acceptable for external use
and shall be rated for the proper application with respect to volt-
age, current, anticipated temperature, flammability, and
mechanical serviceability.
A Patton Model 16F-561 RJ45 to DB-9 adapter is included with
Note
each SmartNode 5400 Series device
Figure 9. Connecting a serial terminal
"Console port" on page 55 for console port pin-outs.
E T
H
0 /1
E T
H
0 /0
C o
n s
o le
R S
-2
3 2
C • Cabling
figure 9.
