SmartNode 5400 Getting Started Guide

Connecting the power supply

The 5400 has the option of an internal or external
that the green Power LED is lit (see figure

Internal AC Power Supply.

WARNING
1. Insert the female end of the AC power to the mains port.
(~120–240V, 50/60 Hz, 1A)
2. Verify that the AC power cord included with your router is compatible with local standards. If it is not,
refer to "Contacting Patton for assistance"
power cord.
3. Connect the male end of the AC power cord to an appropriate AC power outlet.
4. Verify that the green Power LED is lit (see
Installing the gateway router
5)..
• Do not connect power to the AC Mains at this time.
There are no user-serviceable parts in the power supply sec
•
tion of the Model 5400. Contact Patton Electronics Technical
support at (301)975-1007, via our web site at
http://www.patton.com, or by e-mail at support@patton.com,
for more information.
The internal power supply automatically adjusts to accept an
•
input voltage from 100 to 240 VAC (50/60 Hz).
Verify that the proper voltage is present before plugging the
power cord into the receptacle. Failure to do so could result in
equipment damage.
Power
DSL port (optional)
ETH 0/0
10/100/1000Base-T port
10/100/1000Base-T port
Figure 4. 5400 rear panel
on page 41 to find out how to replace it with a compatible
Power
Figure 5. Power LED
figure
Internal AC Power Supply, or an internal or external
E T
H
0 /1
E T
H
0 /0
C o
n s
o le
ETH 0/1
R S
-2
3 2
RESET button
Console
RS-232 port
5).
3 • SmartNode installation
Verify
SN5400
