Patton electronics IPLink 2802 Specifications

Patton IPLink Managed VPN Routers promote business/dual use of broadband access networks
by applying VPN encryption AND QoS/CoS traffic management to traffic flows.
VPN Tunnels
Standard IPSec with AH and ESP ensures maxi-
mum protection when traversing
unsecured networks.
Strong Encryption
DES, 3DES, and AES offer standards based
encryption algorithms from 56 to 256 bits.
QoS/CoS Profiles
Configurable burst tolerance, bandwidth guaran-
tees plus reduce per flow traffic jitter as required
by the application.
Configurable Security Profiles
Built-in IP address and IP port filtering, ACLs and
DoS attack detection creates a comprehensive
security environment.
Enhanced IP Services
DNS resolver and relay, NAT/NAPT, dynamic
DNS, and DHCP server, eases integration.
10/100 Ethernet
Dual 10/100 Ethernet and 5 port Ethernet switch.
SNMP/HTTP Management
Easily manage the IPLink VPN Routers via a sim-
ple web browser interface.
Front panel LEDs
show operational
status at a glance
IP Access Products
IPLink Managed VPN Routers
Model 2802 & 2805
P atton's IPLink Managed VPN Routers
are a family of next generation appli-
ances that address both the security
and the traffic prioritization needs of enter-
prises. VPN routers enable the secure com-
munication of remote offices, home offices,
and mobile users across insecure IP net-
works such as the Internet. IPLink VPN
Routers take it one step further and integrate
quality of service (QoS) to optimize business
traffic flows, allowing dual use (business and
leisure) of broadband connections without
impacting the quality of business communi-
cations.
IPLink VPN Routers implement a comprehen-
sive security environment. It all starts with
IPSec. By supporting ESP as well as AH,
IPLink VPN Routers provide data integrity,
authentication, anti-replay and data confiden-
tiality to any traffic flow. DES, 3DES, and AES
provide standard encryption up to 256 bits.
Firewall capabilities of the IPLink VPN
Routers include Access Control Lists (ACLs),
IP address and port filtering, and protection
against Denial of Service (DoS) attacks.
Internal/external
and AC/DC
power
Proven Patton design
Likewise, PPPoE protocols include support
for PAP and CHAP authentication.
QoS features include
ToS/DiffServ marking
and the configuration of
eight service class tags
per IEEE 802.1p/Q. With
traffic scheduling and
shaping, create dedicat-
ed bandwidth guarantees, configurable burst
tolerance, and policing to include excess traf-
fic discard. IP fragmentation is configurable
to help minimize jitter in traffic flows.
Advanced IP features include RIPv1 & RIPv2
routing and static route configuration. Static
and dynamic NAT, NAPT, DNS resolver and
relay, dynamic DNS, and DHCP server further
add to the capabilities of the IPLink VPN
Router. All IPLink VPN routers can be man-
aged via a web browser (HTTP), command
line interface (Telnet), or an SNMP manage-
ment platform.
For more information, visit us at
www.patton.com.
VPN & QoS software comes standard
10/100 Ethernet WAN
Special Rates
Available
Call for Details
10/100 LAN Ethernet
switch with full-
duplex and auto
MDI/MDI-X
operation
with full-duplex and
auto MDI/MDI-X
operation
