SmartNode 5400 Getting Started Guide

G.SHDSL port

G.SHDSL port
Table 14. RJ45 socket 1000Base-T
Pin Signal
1 TRD0+
2 TRD0-
3 TRD1+
6 TRD1-
4 TRD2+
5 TRD2-
7 TRD3+
8 TRD3-
Table 15. RJ-45 connector
Pin Signal
1 No connection
2 No connection
3 Tip 2
4 Tip 1
5 Ring 1
6 Ring 2
7 No connection
8 No connection
D • Port pin-outs
