SmartNode 4634 and 4638 Series
VoIP Gateway Routers
Quick Start Guide
Approval—This device is approved for connection to the public ISDN telecommunication network,
over BRI/S0-ISDN interfaces.
Zulassung—Zugelassen für die Anschaltung an das öffentliche ISDN Telekommunikationnetz an
BRI/S0-ISDN Schnittstellen.
Aprobación—Este aparato está aprobado para conexión a red publica ISDN sobre interfaz BRI/S0.
Approbation—Cet appareil est approuve pour la connexion au reseau ISDN public avec les interfaces
BRI/S0.
Document Number: 13221U7-001 Rev. B
Part Number: 07MSN4630-QS
Revised: November 17, 2008
Sales Office: +1 (301) 975-1000
Technical Support: +1 (301) 975-1007
E-mail: support@patton.com
WWW: www.patton.com
Advertisement
Table of Contents
Related Manuals for Patton electronics SmartNode 4634 series
Summary of Contents for Patton electronics SmartNode 4634 series
-
Page 1: Quick Start Guide
SmartNode 4634 and 4638 Series VoIP Gateway Routers Quick Start Guide Approval—This device is approved for connection to the public ISDN telecommunication network, over BRI/S0-ISDN interfaces. Zulassung—Zugelassen für die Anschaltung an das öffentliche ISDN Telekommunikationnetz an BRI/S0-ISDN Schnittstellen. Aprobación—Este aparato está aprobado para conexión a red publica ISDN sobre interfaz BRI/S0. Approbation—Cet appareil est approuve pour la connexion au reseau ISDN public avec les interfaces BRI/S0. -
Page 2: Power Up The Smartnode
• This device contains no user serviceable parts. The equipment shall be returned to Patton Electronics for repairs, or repaired by qualified ser- vice personnel. WARNING • Mains Voltage: Do not open the case the when the power cord is attached. -
Page 3: Configuring The Desired Ip Address
Straight-through wired cable LAN (ETH 0/1) Laptop PC Connecting to the PC Figure 1. Connect the PC’s Ethernet port to LAN (ETH 0/1) port of the SmartNode 4630. The SmartNode 4630 Series is equipped with Auto-MDX Ethernet ports, so you can use straight-through Ethernet cables for host or hub/switch connections. -
Page 4: Changing The Wan Ip Address
3.2 Login To access the SmartNode, start the Telnet application on your PC. Type the default IP address into the address field: 192.168.1.1. Accessing your SmartNode via a Telnet session displays the login screen. Type the factory default login: administrator and leave the password empty. Press the Enter key after the password prompt. -
Page 5: Loading The Configuration (Optional)
In general, the SmartNode will connect to the network via the WAN (ETH 0/0) port. This enables the SmartNode to offer routing services to the PC hosts on LAN (ETH 0/1) port. The SmartNode 4630 Series provides an auto- MDX feature for both Ethernet ports, so you can use a straight-through or cross-over cable to connect to a host or a switch (see figure Straight-through wired... -
Page 6: Additional Information
Patton regularly adds new configuration templates to the collection at www.patton.com/voip, so if Note you do not see your application on the CD-ROM, it may have been added to the website. If your application is unique and not covered by any of Patton’s configuration templates, you can man- Note ually configure the SmartNode instead of loading a configuration file template. -
Page 7: Compliance Information
Telephone support: Standard: +1 (301) 975-1007 (USA), Monday–Friday: 8:00 am to 5:00 pm EST (1300 to • 2200 UTC/GMT) Alternate: +41 (0)31 985 25 55 (Switzerland), Monday–Friday: 8:00 am to 5:00 pm CET (0900 to 1800 • UTC/GMT) Fax: +1 (253) 663-5693 (USA) or +41 (0)31 985 25 26 (Switzerland) -
Page 8: Isdn Compliance
B.3 ISDN compliance This device is approved for connection to the public ISDN telecommunication network. When this device is used in North America, it shall be connected to a Network Termina- tion Device and not connected directly to an outside POTS line. CAUTION B.4 CE Declaration of Conformity Product Description:... -
Page 9: Copyright Statement
Trademarks statement The term SmartNode is a trademark of Patton Electronics Company. All other trademarks presented in this docu- ment are the property of their respective owners. Warranty, Trademark, & Compliance Information For warranty, trademark and compliance information, refer to the Models SN4630 Series Getting Started Guide located on the CD-ROM that came with your VoIP Gateway Router or available online at www.patton.com. - Page 10 Notes ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ SmartNode 4634 & 4638 Quick Start Guide...
