SmartNode 5400 Getting Started Guide
LED
Note
Power
Run
VoIP Link
Ethernet Link
Ethernet Speed
10/100
Ethernet Speed
1000
Ethernet Activity
G.SHDSL ACT
(Rear panel)
G.SHDSL LINK
(Rear panel)
SmartNode 5400 front panel
Table 4. SN5400 Front and Rear panel LEDs
If an error occurs, all LEDs will flash once per second.
When lit, indicates power is applied.
When lit, the unit is in normal operation. Flashes once per second during
boot (startup).
On indicates the gateway is registered to an H.323 gatekeeper/SIP server, or,
•
in the case of direct routing, has at least one active VoIP connection.
Off indicates the unit is not configured or registered, or has no active direct-
•
routed VoIP connection.
Flashing green indicates that the unit is attempting to register or has failed
•
to register.
On when the Ethernet connection on the corresponding port has a
•
link indication.
When the Ethernet Link LED is on, then:
On when the Ethernet is connected to a 100Mb network.
•
Off when the Ethernet is connected to a 10Mb network.
•
On when the Ethernet is connected to a 1000Mb network.
•
• Flashes when data is received or transmitted at the corresponding Ethernet port.
• Flashes when data is received or transmitted
Off = No activity
•
On when the G.SHDSL connection on the corresponding port has a
•
link indication.
• Off = No G.SHDSL connection
1 • General information
Description
19
