SmartNode 5400 Getting Started Guide

SmartNode 5400 overview

The SmartNode 5400 Enterprise Session Border Router
enables Universal SIP Trunking and provides a single Inte-
grated Access Device with features like IP Routing, Redun-
dancy, Security and a SIP registrar for survivability. In
addition, the SN5400 enables Transcoding between two
networks to most optimally support the bandwidth require-
ments. It is an essential device to connect Enterprise IP tele-
phony to cost-effective SIP Trunking through the limited
WAN access bandwidth. The SN5400 connects to the
Enterprise's LAN to an Internet telephony service provider
(ITSP), creating a single conduit for multimedia compo-
nents including voice, video and data.
The SmartNode 5400 Enterprise Session Border Router performs the following major functions:
• Enterprise Session Border Router with Transcoding: Enables up to 64 transcoding sessions between
codecs
• Secure Enterprise: Enable VPN, NAT/NAPT, Access Control Lists with Downstream QoS to ensure the
most efficient use of your bandwidth
• IP Routing: RIP v1/v2, VRRP, policy based routing, loopback interface
• Universal Interface support for WAN: Support for G.SHDSL, PRI and Gigabit Ethernet interfaces for
your WAN needs
• VPN Tunnels: Standard IPsec with AH and ESP ensures maximum protection when traversing unsecured
networks
• Configurable Security Profiles: Built-in IP address and IP port filtering, ACLs and DoS attack detection
creates a comprehensive security environment.

SN5400 model codes

The SmartNode 5400 series consists of several models. They differ in the number of transcoding sessions they
can support. All models come equipped with two 10/100/1000 Base-T Ethernet ports. The SmartNode 5400
models are listed in table
SN5400/32P/EUI
SN5400/64P/EUI
SN5400/32P2GS/EUI
SN5400/64P2GS/EUI
SmartNode 5400 overview
2.
Table 2. SmartNode 5400 Models
Model Transcoding Sessions G.SHDSL Port
32
64
32
64
1 • General information
0
0
1
1
