Flashforge Creator Pro User Manual page 27

①Preview: Choose to enter preview interface or not
②Print when slice done: Print or not when slice done
③Material type: Choose according to the type of model
④Supports: When print with model contains part hanging in the air or top-heavy, support is
[supports]
necessary. Click
⑤Raft: This function will help the model to stick well on the platform.
⑥Wall: During dual color printing, this function will help to clear the leaking filament of another
extruder.
⑦Vase Mode: No capping for the model
⑧Resolution：You have three resolution solution(with default setting)to choose from, high
resolution is corresponding with slow printing speed, opposite for the low resolution.For PLA
printing, an extra solution "Hyper" is available.
⑨More options: Click
Different resolution solution is corresponding to different defaults, click
to default setting.
●Layer
a. Layer: Layer thickness of the printing model. With a small number, the surface of the model
will be more smooth.
b. First Layer Height: This is the first layer of the model, which will affect the sticking
performance between the model and platform. Maximize is 0.4mm, usually the default is ok.
c. Shell: Contains of the outside shell number, capping layer number (under vase pattern, top
solid layer setting is invalid.)
● Primeter Shells: Maximize is 10
a. Top Solid Layer: Maximize is 10, minimum is 1.
b. Bottom Solid Layer: Maximize is 10, minimum is 1.
● Infill
a. Fill Density means fill rate.
b. Fill Pattern is the pattern of filling shape which effects printing duration.
c. Combine Infill: You can select the layers for combining according to the layer thickness.
The combined thickness should not exceed 0.4mm. "Every N layers" is for all the infills while
"Every N inner layers" is only for inner infills, which generally can save print time.
to create support part for the printing.
[More options] to set for layer, shell, infill, speed and temperature.
27
[Restore Defaults]
to back
