CyberData VoIP Intercom 010935F Operation Manual page 51

2. On the Multicast Configuration page, enter values for the parameters indicated in
Web Page Item
Enable Multicast Operation
Device Settings
Priority
Address
Port (range can be from 2000 to 65535)
Multicast Group Name
3. After changing the parameters, click on the Save button.
4.2.8.1 Assigning Priority
When playing multicast streams, audio on different streams will preempt each other according to
their priority in the list. An audio stream with a higher priority will interrupt a stream with a lower
priority.
If both SIP and Multicast is enabled, SIP audio streams are considered priority 4.5. SIP audio will
interrupt multicast streams with priority 0 through 4 and will be interrupted by multicast streams
with priority 5 through 9.
During priority 9 multicast streams, the analog volume control is bypassed and the volume level is
set to maximum.
Note
Ringtones and Ringtones all play at the same priority level. This means that it is possible to have a nightring tone
Nightringtones
and a normal ringtone playing at the same time.
Operations Guide
Table 4-14. Multicast Configuration Parameters
SIP calls, multicast streams, ring tones, ringback tones, and nightring tones are all
prioritized.
930242M
Description
Enables or disables multicast operation.
Indicates the priority for the multicast group. Priority 9 is the
highest (emergency streams). 0 is the lowest (background
music). See Section 4.2.8.1, "Assigning Priority"
details.
Enter the multicast IP Address for this multicast group (15
character limit).
Enter the port number for this multicast group (5 character
limit).
Note: The multicast ports have to be even values. The
webpage will enforce this restriction.
Assign a descriptive name for this multicast group (25
character limit).
Click the Save button to save your configuration settings.
Note: You need to reboot for changes to take effect.
Click on the Reboot button to reboot the system.
Installing the VoIP Intercom
Intercom Setup
Table 4-14.
for more
CyberData Corporation
45
