CyberData VoIP Intercom 010935F Operation Manual page 40

2. On the SIP Configuration page, enter values for the parameters indicated in
Web Page Item
Enable SIP Operation
SIP Settings
SIP Server*
Remote SIP Port*
Local SIP Port*
Outbound Proxy
Outbound Proxy Port
SIP User ID*
Authenticate ID*
Authenticate Password*
Register with a SIP Server*
Re-registration Interval (in seconds)*
Unregister on Reboot*
RTP Settings
RTP Port (even)
Dial Out Settings
Dial Out Extension
Extension ID
Operations Guide
Table 4-9. SIP Configuration Parameters
Description
Enables or disables SIP operation.
Type the SIP server represented as either a numeric IP
address in dotted decimal notation or the fully qualified
host name (255 character limit [FQDN]).
Type the Remote SIP Port number (default 5060)
(8 character limit).
Type the Local SIP Port number (default 5060)
(8 character limit).
Type the Outbound Proxy as either a numeric IP address in
dotted decimal notation or the fully qualified host name
(255 character limit [FQDN]).
Type the Outbound Proxy Port number (8 character limit).
Type the SIP User ID (up to 64 alphanumeric characters).
Type the Authenticate ID
(up to 64 alphanumeric characters).
Type the Authenticate Password (up to 64 alphanumeric
characters).
Check this box to enable SIP Registration.
For information about Point-to-Point Configuration, see
Section 4.2.5.2, "Point-to-Point
Type the SIP Registration lease time in minutes (default is
60 minutes) (8 character limit). Re-registration Interval (in
seconds)*
When selected, on boot, the device will first register with a
SIP server with a expiration delay of 0 seconds. This has
the effect of unregistering any current devices on this
extension.
Specify the port number used for the RTP stream after
establishing a SIP call. This port number has to be an even
number and defaults to 10500.
Type the dial out extension number (64 character limit).
Note: For information about dial-out extension strings and
DTMF tones, see
Strings and DTMF Tones (using
Type the desired Extension ID (64 character limit).
Click the Save button to save your configuration settings.
Note: You need to reboot for changes to take effect.
930242M
Installing the VoIP Intercom
Table
Configuration".
Section 4.2.5.1, "Dial Out Extension
rfc2833)".
CyberData Corporation
34
Intercom Setup
4-9.
