BIO RAD SmartSpec 3000 Instruction Manual page 6

10
9
Fig. 3. View of the SmartSpec 3000 sample compartment.
9. Cuvette chamber
10. Cuvette storage compartment
11. Cuvette spring
12. Light path
Fig. 4. View of the SmartSpec 3000 integrated thermal printer paper with door removed.
13. Thermal printer paper
14. Printer paper shaft
Insert cuvette into the cuvette chamber. Insure that the
cuvette is placed in the proper orientation with respect to
the light path.
Storage space for cuvette.
Aligns cuvette. Accommodates various cuvette
configurations.
Light path axis.
14
13
Roll of thermal printer paper.
3
11
12
