12.5 PC Serial Connection Instructions

1. Connect RS232 9-pin serial cable from SmartSpec 3000 to computer.
2. Using a terminal program (e.g. HyperTerminal), set the connection to 9600 baud, 8 bits-
no-parity-1 stop bit (9600-8-N-1), no flow control.
3. In addition to the actual data transmission/reception parameters, other parameters in
HyperTerminal may have to be set. The correct settings may vary from computer to
computer, but these are settings currently used and offered as an example. It may not be
necessary to implement all parameters. Only the Connect Direct to Com Port is essential.
From the main HyperTerminal menu
File
Properties
Open the properties dialog box. Using the tabbed HyperTerminal properties box:
Connect To
Connect using Direct to Com [n] (n = serial port number). This must be set.
Settings
Terminal Keys
Del
Emulation
Tel net terminal
Terminal Setup
Underline
Blink
Backscroll buffer line 500
ASCII Setup
Echo typed characters locally
Wrap lines that exceed terminal width
4. When the SmartSpec 3000 sends data, either when requested from Scan, or Kinetics, or
when the user activates the data echo toggle in Setup, the data streams to the terminal
window.
ANSI
ANSI
