7
SELCALL (Selective Calling)
Receiving
D Receiving an individual Selcall
When receiving an RX code:
• Beeps sound.
• The RX code's text is displayed, if entered.
• "ë" and channel name blink, and the Selcall mute is
released.
➥ Hold down [PTT] and speak at your normal voice
level.
NOTE:
• If the ID decode function "ID Dec" is turned ON,
the received Own ID code is displayed instead
of the text, and stored into the transceiver. This
function can be turned ON using the CS-410PRO
.
cloning software
• A maximum of 8 individual RX codes can be
stored into the transceiver.
D Receiving a Group call
When receiving a Group call:
• Beeps sound.
• "ë" and "GROUP" blink, and the Selcall mute is released.
➥ Hold down [PTT] and speak at your normal voice
level.
• You can set the Group call receiving options using the
optional CS-410PRO
cloning software
410PRO help file for more information.
When the Quiet mode is ON, the Selcall mute function
is activated and enables silent operation until a Selcall
code is received.
1) Enter the Set mode.
➥ Hold down [FUNC] for 2 seconds.
2) Select the "QUIET" menu.
➥ Push [FUNC].
3) Turn the Quiet mode ON or OFF.
➥ Push[UP]/[DOWN].
4) Exit the Set mode.
➥ Hold down [FUNC] for 2 seconds.
If the transceiver is in the Stun mode, it will request a
password when you turn ON the transceiver.
This function can only be set by your dealer. Once the
password has been entered, the transceiver will not
prompt you to enter it again.
Cloning and transceiver operations are disabled
after a Kill ID is received. By activating the Clone
Write mode, you can use the transceiver again. (The
internal data cannot be accessed using the Clone
Read mode.)
. Consult the CS-
7-4
Quiet mode
• "Q" is displayed when the Quiet mode is ON.
NOTE: The Unmute mode may automatically return
to the Mute mode after a specified time period,
depending on the presetting.
Stun function
- Quick Links:
- Basic Operation
Hide quick links:
Advertisement
Chapters
Table of Contents
Need help?
Do you have a question about the IC-410PRO and is the answer not in the manual?
Questions and answers
I have the ic-41 pro. I can transmit but no longer receive. I’m not aware of any settings changing. I’m using ch15. The screen shows sql , q and below that. OS S in black squares
Your Icom IC-410PRO may be able to transmit but not receive on channel 15 due to one or more of the following reasons:
1. Quiet Mode (Selcall or Tone Squelch) is ON – If Quiet Mode is enabled, the radio will not unmute unless it receives the correct Selcall or tone. Turn OFF Quiet Mode in the Set mode.
2. Tone Squelch setting mismatch – If the tone squelch is set incorrectly or does not match the other radios, you will not hear incoming transmissions. Set the correct tone squelch setting for the user group.
3. Squelch level is set too high – If the squelch level is too high, weak signals may be blocked. Decrease the squelch level in the Set mode.
4. Monitor function is OFF – If the Monitor function is OFF, you might not hear transmissions that don’t match the squelch settings. Press [MONI] to temporarily open the squelch and check for incoming signals.
Check and adjust these settings to restore receiving capability on channel 15.
This answer is automatically generated
