3
SET MODE
Set mode items (Continued)

D Squelch Level "SQL"

The Squelch circuit eliminates background noise
when no signals are present. Set the level to where
the noise just disappears, for proper operation.
A higher level is better for inner cities or noisy areas,
and a lower level is more beneficial in quiet, rural or
country areas. (0 = lowest, 9 = highest)
Squelch Level 2 (default)

D Scan mode "SCAN-M"

Select the desired scan mode. See page 5-2 for
details.
Open scan (default)
Priority scan

D CTCSS/DTCS

Select the desired CTCSS tone frequency or DTCS
code. You can change between CTCSS and DTCS
setting modes by pushing [MONI].
See page 6-2 for more information about CTCSS and
DTCS.
CTCSS Tone Frequency
Setting mode (default)
Squelch Level 0
Group scan
Repeater scan
[MONI]
DTCS Code Setting mode

D Backlight "LIGT"

The transceiver features a backlit LCD display for use
in low-light conditions. You can select the backlight
mode in the Set mode.
ON: Backlight is continuously ON.
DIM: The backlight continuously lights dimly.
DMA: When a signal activates the dimmer pin on the
connected OPC-1939
lights dimly. When no signal is applied to the pin,
the backlight is turned ON.
AU2: The backlight automatically turns ON for 5
seconds when changing the contents displayed
on the LCD.
AUT: Lights for 5 seconds when you transmit or
receive a Selcall signal, or when you push any
key except [PTT].
OFF: No backlight.
Backlight Auto (default)

D Beep "BEEP"

The confirmation beep is set to ON as the default. You
can turn OFF the beep for silent operation in the Set
mode.
Beep ON (default)

D Beep Level "BEPV"

You can set the volume level for the key beeps to
between 1 (soft) and 5 (loud).
Beep level 3 (default)

D RF Power "RFPOW"

Set the RF power to High or Low.
RF Power High (default)
3-3
, the backlight
acc cable
Backlight ON
Beep OFF
Beep level 1
RF Power Low
