9
SPECIFICATIONS
Specifications
D General
• Frequency coverage:
CB
RX/Private
• Type of emission:
CB
RX/Private
• Channel spacing:
CB
RX/Private
• Current drain (at 13.8 V):
TX (at 5 W)
TX (at 25 W)
Max. audio
• Operating temperature range:
• Power supply requirement:
• Frequency stability:
• Antenna impedance:
• Dimensions:
• Weight:
D Transmitter
• Output power:
CB
Private
• Modulation system:
• Max. frequency deviation:
Narrow
Wide
• Spurious emissions:
D Receiver
• Sensitivity (12 dB SINAD):
• Squelch sensitivity:
• Intermodulation rejection ratio:
• Spurious response rejection ratio: 70 dB (minimum)
• Audio output power:
All stated specifications are subject to change without notice or obligation.
476.4250–477.4125 MHz
450.0000–520.0000 MHz
8K50F3E
8K50F3E/16K0F3E
12.5 kHz
12.5/25 kHz
approximately 4.0 A
approximately 7.0 A
approximately 1200 mA
–30°C to +60°C
13.8 V DC nominal (Negative ground)
±2.5 ppm (–30°C to + 60°C)
50 Ω nominal
W 150 × H 40 × D 117.5 mm (Projections not included)
approximately 800 g
5 W/1 W
25 W/5 W/1 W
Variable reactance frequency modulation
±2.5 kHz
±5.0 kHz
–30 dBm (maximum)
0.25 μV (typical)
0.25 μV (typical)
75 dB (typical)
4.0 W (typical) at 5% distortion into a 4 Ω load
9-2
