5
SCAN
Scan types
The transceiver has 4 scan types to search for
signals, Tag function and 4 Resume options, for
scanning versatility.
OPEN SCAN
#
ch 01
#
ch 40
#
ch 39
Repeatedly scans all tagged channels in sequence.
" " = Tagged channel.
#
An Open scan automatically searches for busy
channels and enables you to locate new stations for
communication or listening.
GROUP SCAN/PRIORITY SCAN
#
ch 02
#
ch 01
Priority
channel
#
ch 10
#
ch 09
Repeatedly checks the preset Priority
channel after scanning 5 tagged channels.
" " = Tagged channel.
#
Group scan and Priority scan repeatedly searches for
a signal on the Priority channel while scanning the
tagged channels. This is useful when waiting for a call
on the Priority channel or several tagged channels.
Group and Priority scans are performed differently
while transmitting. Group scan transmits on a Priority
channel or on a busy channel, and Priority scan
transmits only on the Priority channel.
Tagged channels are independently set for Open,
Group and Priority scans. All channels may be preset
as tagged channels for all scans.
#
ch 02
ch 03
ch 04
#
#
ch 06
ch 05
#
#
ch 03
ch 04
#
ch 05
#
ch 06
#
#
ch 08
ch 07
REPEATER SCAN
Scan cancel
#
Ch 48
#
Ch 04
" " = Tagged channel.
#
Scans all repeater channels (01 to 08 and 41 to 48)* in
sequence. If there are no busy channels after scanning
channels 01 to 08 and 41 to 48,* the scan begins from 01
again, and then the transceiver transmits a signal to search
for a repeater while scanning.
* Excludes emergency repeater 05.
• Repeater scan flow
Scan start
channel
Scan is automatically cancelled.
NOTE: Scan excludes the emergency repeater channel 05.
5-2
#
#
#
Ch 01
Ch 02
Ch 48
#
#
Ch 03
Ch 02
Blinks
Searches for
signals on the
Scan
repeater output
channels.
Automatically tries to
access the repeater.
(0.5 seconds)
Waits for a signal from
the repeater.
(0.5 seconds)
(When no reply signal is received.)
Automatically tries
to access the next
repeater.
Scan
#
Ch 01
