6
TONE SQUELCH AND POCKET BEEP
Tone Squelch
The transceiver is equipped with 51 CTCSS
(subaudible) tone frequencies, and 104 DTCS codes.
CTCSS/DTCS operation enables you to communicate
in the silent standby mode, since you will only receive
calls from group members using the same CTCSS
tone frequency or DTCS code.
NOTE: CTCSS/DTCS function is not selectable on
CB channel 5, 35, and Repeater channel 5.
Information
The transceiver has 51 tone frequencies and
consequently their spacing is narrow compared to
units having 38 tones.
Therefore, some tone frequencies may receive
interference from adjacent tone frequencies.
D Setting the
CTCSS tone frequency/DTCS code
1) Enter the Set mode.
➥ Hold down [FUNC] for 2 seconds.
2) Select the CTCSS/DTCS menu.
➥ Push [FUNC].
• Selected CTCSS or DTCS code is displayed.
• Push [MONI] to select between CTCSS and DTCS
to enter the Setting mode.
CTCSS Setting mode
CTCSS tone frequency
List number
3) Set the desired CTCSS tone frequency or DTCS
code.
➥ Push [UP]/[DOWN].
4) Exit the Set mode.
➥ Hold down [FUNC] for 2 seconds.
DTCS Setting mode
[MONI]
DTCS code
List number
Selectable CTCSS tone frequency list
No. Freq. No. Freq.
01 67.0 12 94.8
02 69.3 13 97.4
03 71.0 14 100.0
04 71.9 15 103.5
05 74.4 16 107.2
06 77.0 17 110.9
07 79.7 18 114.8
08 82.5 19 118.8
09 85.4 20 123.0
10 88.5 21 127.3
11 91.5 22 131.8
Selectable DTCS code list
No. Code No. Code
01 023 22 131
02 025 23 132
03 026 24 134
04 031 25 143
05 032 26 145
06 036 27 152
07 043 28 155
08 047 29 156
09 051 30 162
10 053 31 165
11 054 32 172
12 065 33 174
13 071 34 205
14 072 35 212
15 073 36 223
16 074 37 225
17 114 38 226
18 115 39 243
19 116 40 244
20 122 41 245
21 125 42 246
D Turning ON the Tone Squelch
Before turning ON the Tone Squelch, set the desired
CTCSS tone frequency or DTCS code in the Set
mode.
➥ Hold down [MONI] for 2 seconds to turn ON the
Tone Squelch.
• Holding down [MONI] for 2 seconds switches
between "TSQL" (Tone Squelch), "TSQL ë"
(Pocket Beep) and OFF (cancel).
6-2
No. Freq. No. Freq. No.
23 136.5 34 177.3 45
24 141.3 35 179.9 46
25 146.2 36 183.5 47
26 151.4 37 186.2 48
27 156.7 38 189.9 49
28 159.8 39 192.8 50
29 162.2 40 196.6 51
30 165.5 41 199.5
31 167.9 42 203.5
32 171.3 43 206.5
33 173.8 44 210.7
No. Code No. Code No.
43 251 64 371 85
44 252 65 411 86
45 255 66 412 87
46 261 67 413 88
47 263 68 423 89
48 265 69 431 90
49 266 70 432 91
50 271 71 445 92
51 274 72 446 93
52 306 73 452 94
53 311 74 454 95
54 315 75 455 96
55 325 76 462 97
56 331 77 464 98
57 332 78 465 99
58 343 79 466 100
59 346 80 503 101
60 351 81 506 102
61 356 82 516 103
62 364 83 523 104
63 365 84 526
(Hz)
Freq.
218.1
225.7
229.1
233.6
241.8
250.3
254.1
Code
532
546
565
606
612
624
627
631
632
654
662
664
703
712
723
731
732
734
743
754
