Setup Parameters, cont'd.
Media, cont'd.
Direct Thermal Papers (Europe)
DT Type/ Paper
Speed Designation
Top Coated/ Top Board
Standard Premium
Non Top Coated/ Economy
Standard Eco Board
Top Coated/High Premium High Speed
Direct Thermal Papers (North America)
DT Type/ Paper
Speed Designation
Top Coated/ Duratherm II Tag
Standard Duratherm II
Top Coated/ Duratherm Ltg
High Duratherm IR
1
/. Please note that preprint and varnish decrease the sensitivity of the direct thermal paper.
2
/. May require increased printhead pressure (see chapter 12 "Adjustments; Printhead Pressure").
3 /. Exceeding the recommended print speed may, even in case of plain text printing, cause premature wear-out of the
printhead
Intermec EasyCoder F2 – Installation & Operation Ed. 2
Recommended Settings
Intermec recommends the paper type and print speed settings listed
below to produce the highest possible print quality under normal
conditions and to ensure maximum lifetime of the printhead. Use
the EasySet bar code wand for easy media setup. Label materials
are available from Intermec either in standardized types and sizes,
or in special materials and sizes on request.
When adjusting the image darkness for individual requirements or
new label materials, proceed as follows:
Keep the Label Factor at the recommended value for the type
of direct thermal paper. Then decrease or increase the Label
Constant for lighter or darker images respectively, depending on the
requirements of the images or of the new label material.
General Paper Type Settings Guide
Sensitivity
Low
Standard
High
Ultra high
Label Label
Constant Factor
2 100
95
85
2
80
85
Label Label
Constant Factor
2 112
95
92
82
1
Label Constant
100 – 115
86 – 99
70 – 85
50 – 69
Picket Fence Bar Code
40
40
40
40
40
Picket Fence Bar Code
40
40
40
40
Chapter 6 Setting Up the Printer
Label Factor Max. Speed
40
40
40
40
Max Rec. Print Speed (mm/sec)
Ladder Bar Code
100
125
125
175
175
Max Rec. Print Speed (mm/sec)
Ladder Bar Code
100
100
175
150
3
100
125
175
200
3
100
125
125
175
175
3
100
100
175
150
