Peel-Off - Intermec easycoder f2 Installation & Operation Manual

Peel-Off

1
Open the side door.
Intermec EasyCoder F2 – Installation & Operation Ed. 2
The EasyCoder F2 can print on labels, tickets, tags, and paper strip
in various forms. This chapter describes the case when self-adhesive
labels are separated from a backing paper (liner) immediately
after printing after which the backing paper is rewound internally
in the printer.
Peel-off operation cannot be performed when quick-load guides
are fi tted.
Use the <Feed> key (see fi gure #14) when loading the same type of
paper as before. When switching to a new type of media or when the
printer does not feed out the paper properly, simultaneously press
the < Shift> and <Feed> keys.
Peel-off can only be used for:
• Self-adhesive labels on backing paper
An optional label-taken sensor can hold the printing of next label
in a batch until the present label has been removed, see chapter
9 "Options".
2
Turn the printhead lift knob clockwise to lift
Chapter 5 Paper Load
the printhead.
35
