I Set mode programming

Set mode is used to change the conditions of the transceiver's
functions: Scan type, Scan resume timer, Weather alert,
Dual/Tri-watch, Beep tone, LCD contrast, Automatic foghorn fre-
quency, Radio power, Scrambler type* and Scrambler code.*
*Appears only when the optional scrambler unit is installed.
Available functions may differ depending on how they are
set by the dealer.
q Turn power OFF.
w While pushing and holding [16•9], turn power ON to enter

Set mode.

e After the display appears, release [16•9].
r Rotate [DIAL] to select the desired item, push
[DIAL•ENTER].
t Rotate [DIAL] to select the desired condition of the item.
y Push [CLR], or rotate [DIAL] to select "E E x x i i t t ," then push
[DIAL•ENTER] to exit set mode and returns to normal op-
eration condition.
• SET MODE CONSTRUCTION
˘Scan Type
Rotate
--Set Mode--
Scan Timer
WX Alert
Dual/Tri
Beep
Contrast
Foghorn Frequency
Radio Power
Scrambler Type
Scrambler Code
Exit
SET MODE

I Set mode items

D Scan type
The transceiver has 2 scan types: Normal scan and Priority
scan. Normal scan searches all TAG channels in the selected
channel group. Priority scan searches all TAG channels in se-
quence while monitoring Channel 16.
--Set Mode--
Scan Type
Priority
˘Normal
<ENT˘OK>
Default: Normal
D D Scan resume timer
The scan resume timer can be selected as a pause (OFF) or
timer scan (ON). When OFF is selected, the scan pauses
until the signal disappears. When ON is selected, the scan
pauses 5 sec. and resumes even if a signal has been re-
ceived on any other channel than Channel 16.
--Set Mode--
Scan Timer
ON
˘OFF
<ENT˘OK>
Default: OFF
