CONNECTING ENERVISTA 745 SETUP TO THE RELAY
Note
NOTE
4–18
The Front Panel settings window will open with a corresponding status indicator on the
lower left of the EnerVista 745 Setup window.
If the status indicator is red, verify that the serial cable is properly connected to the relay,
and that the relay has been properly configured for communications (steps described
earlier).
The front panel setpoints can now be edited, printed, or changed according to user
specifications. Other setpoint and commands windows can be displayed and edited in a
similar manner. Actual values windows are also available for display. These windows can
be locked, arranged, and resized at will.
Refer to the EnerVista 745 Setup help file for additional information about the using the
software.
