CyberData 011102 series Operation Manual page 37

4. On the Test IP Speaker page, Enter a number into the Test duration field.
5. Click Test.
6. You will hear a tone from the speaker being testing.
7. After the test, click Cancel to return to the IP Configuration page.
Test duration
Note
Operations Guide
Identifying and Testing a Ceiling Speaker when Using InformaCast 4.0 or Later
View Speaker's Status Page
When viewing the speaker's status page via Informacast, Informacast links to the wrong
port and path.
Informacast expects our speaker's status page to be at:
http://<ipaddr>:10004/status.
The status page is actually at:
http://<ipaddr>/ (port 80)
Therefore, if a user clicks the link to view the status page and is directed to:
http://10.10.10.10:1004/status
The user will need to edit the url in the address bar to:
http://10.10.10.10/
Figure 2-22. Test IP Speaker Page
Cancel
930320G
Installing the Singlewire-enabled Speaker
Test
CyberData Corporation
30
