3. On the Home Page, review the setup details and navigation buttons described in
Web Page Item
Device Settings
Change Username
Change Password
Re-enter Password
Current Settings
Serial Number
Mac Address
Firmware Version
IP Addressing
IP Address
Subnet Mask
DNS Server 1
DNS Server 2
Boot Time
Current Time
InformaCast Server
Configuration File
B'casts Accepted
B'casts Rejected
B'casts Rejected
RTP Packets Rx'd
Clock Status
Clock Firmware
Miscellaneous Settings
Beep on Initialization
Disable Volume Control Dial
Operations Guide
Table 2-5. Home Page Overview
Description
Type in this field to change the username (25 character limit).
Type in this field to change the password (19 character limit).
Type the password again in this field to confirm the new password
(19 character limit).
Shows the device serial number.
Shows the device Mac address.
Shows the current firmware version.
Shows the current IP addressing setting (DHCP or Static).
Shows the current IP address.
Shows the current subnet mask address.
Shows the current DNS Server 1 address.
Shows the current DNS Server 2 address.
Shows the boot time.
Shows the current time.
Shows the InformaCast Server IP address.
Shows the configuration file.
Shows the number of B'casts accepted.
Shows the number of B'casts rejected.
Shows the number of active B'casts.
Shows the number of RTP packets Rx'd.
Shows the current clock status.
Shows the current clock firmware version.
Select either Yes or No to indicate if you want to hear a beep when
the unit is powered up.
When selected, the volume control dial will be disabled.
Click the Save button to save your configuration settings.
Note: You need to reboot for changes to take effect.
Click on the Reboot button to reboot the system.
930320G
Installing the Singlewire-enabled Speaker
Configure the Speaker Parameters
Table
CyberData Corporation
18
2-5.
