2.2.1.2 Singlewire-enabled Speaker (with PoE Injector) to a 802.3af Compliant PoE
Switch
In Figure
separately). A PoE Injector is a power supply solution for those who have a standard Non PoE
Switch.
Figure 2-5. Singlewire-enabled Speaker Speaker (with PoE Injector) to a Non PoE Switch
Operations Guide
2-5, if a PoE switch is not available, you will need a PoE Injector, part #010867A (ordered
Non PoE Switch
PoE Injector (Part #010867A)
Cat 5 Ethernet cable
930320G
Installing the Singlewire-enabled Speaker
Set Up and Test the Speaker
Speaker
