2.2.1.3 Running the Singlewire-enabled Speaker with Auxiliary Power

Figure

Network connection or from an external source.

Operations Guide

2-6, the power for the Singlewire-enabled Speaker can either come from an 802.3af

Figure 2-6. Running the V2 Speaker with Auxiliary Power

12-14 VDC

GND

AC adaptor

12-14 VDC @ 3 Amps

Speaker

AUX POWER (+)

(+12VDC @ 1A)

AUX POWER (-)

J10

930320G

Installing the Singlewire-enabled Speaker

Set Up and Test the Speaker

AUX SPEAKER (-)

AUX SPEAKER (+)

LINE OUT (-)

LINE OUT (+)

CyberData Corporation
