Acoustic Noise: < 52dB sound pressure at 5 ~ 28°C (41 ~
82°F)
•
Altitude: 0 to 3,048 m (0 ~ 10,000ft)
•
Safety: CE compliant, UL/cUL

1.4 Power Supply Options

1.4.1 300W ATX Power Supply with PFC (PS-300ATX-ZB)
•
Output rating: 300 watts max.
•
Input rating: 90 ~ 264 Vac @ 47 ~ 63 Hz (Full range)
•
Output voltage: +5 V @ 30 A, +3.3 V @ 28 A , +12 V @
15 A, -5 V @ 0.3 A, -12 V @ 0.8 A, +5 VSB @ 2 A
•
Minimum load: +5 V @ 0.1 A, +3.3 V @ 0.3 A
•
MTBF: 100,000 hours @ 25° C, full load
•
Safety: UL/cUL/TUV/Nemko/FCC/CE/CB/CCC
1.4.2 300W ATX Redundant Power Supply (RPS-300ATX-Z)
•
Output rating: 300 watts max.
•
Input rating: 90 ~ 264 Vac @ 47 ~ 63 Hz (Full range)
•
Output voltage: +5 V @ 25 A, +3.3 V @ 18 A, +12 V @ 16
A, -5 V @ 0.5 A, -12 V @ 0.5 A, +5 VSB @ 2 A
•
Minimum load: +5 V @ 3 A, +3.3 V @ 1 A, +12 V @ 2 A,
+5 VSB @ 0.1 A
•
MTBF: 150,000 hours @ 25° C, full load
•
Safety: UL/cUL/TUV/FCC/CE/CB/CCC
1.4.3 400W ATX Power Supply (PS-400ATX-ZB)
•
Output rating: 400 watts max.
•
Input rating: 90 ~ 240 Vac @ 47 ~ 63 Hz (Full range)
•
Output voltage: +5 V @ 35 A, +3.3 V @ 25 A, +12 V @
30A, -5 V @ 0.8 A, -12 V @ 1.0 A, +5 VSB @ 2 A
