4.4 Thermal Sensor

There is one temperature sensor inside the chassis, See Figure 4-1.to find
the location.
When the temperature rises, the temperature sensor sends a signal to the
alarm board and a continuous alarm will sound. To stop the alarm,
press the Alarm Reset Switch on the Front Panel.
Figure 4-2 Thermal sensor
2 7
Thermal
r
Senso
