  • Page 1 User Manual IPC-7220 Desktop/Wallmount IPC Chassis for ATX Motherboard...
  • Page 2 The documentation and the software included with this product are copyrighted 2009 by Advantech Co., Ltd. All rights are reserved. Advantech Co., Ltd. reserves the right to make improvements in the products described in this manual at any time without notice.

  • Page 3: Safety Instructions

    Discard used batteries according to the manufacturer's instructions. THE COMPUTER IS PROVIDED WITH CD DRIVES COMPLY WITH APPRO- PRIATE SAFETY STANDARDS INCLUDING IEC 60825. CLASS 1 LASER PRODUCT KLASSE 1 LASER PRODUKT IPC-7220 User Manual...
  • Page 4 CAUTION: Any unverified component could cause unexpected damage. To ensure the correct installation, please always use the components (ex. screws) provided with the accessory box. IPC-7220 User Manual...

  • Page 5: Table Of Contents

    Figure 2.4 Hold-down clamp installation........9 Bi-directional mounting................9 Figure 2.5 Bottom and Right-side of mounting ......9 Chapter Operation..........11 The Front Section of IPC-7220 ............... 12 3.1.1 Switches..................12 3.1.2 LED indicators................12 Table 3.1: System status LED summary ........12 Replacing the Fan ...................
  • Page 6 Figure A.1 Exploded diagram ............ 24 Table A.1: Table A.1: Parts List ..........25 Appendix B Optional Backplanes ......27 Motherboard Options ................28 Table B.1: ATX motherboard options ........28 Table B.2: MicroATX motherboard options........ 28 IPC-7220 User Manual...

  • Page 7: Chapter 1 General Information

    Chapter General Information This chapter provides general information about the IPC-7220. Sections include: ! Introduction ! Specifications ! Power supply options ! Environmental specifications ! Dimension of IPC-7220...

  • Page 8: Introduction

    Supporting ATX motherboards and up to five PCI and two ISA full-length cards, the IPC-7220 allows a wide range computing peripherals to be inte- grated with the chassis.

  • Page 9: Environmental Specifications

    V @ 1.0 A, +5 VSB @ 2 A Minimum load: +5 V @ 3 A, +3.3 V @ 1 A, +12 V @ 2 A, +5 VSB @ 0.1 A MTBF: 100,000 hours @ 25°C, full load Safety: UL/cUL/TUV/FCC/CE/CB/CCC IPC-7220 User Manual...

  • Page 10: 400W Atx Redundant Power Supply (Rps-400Atx-Z)

    V @ 0.8 A, +5 VSB @ 2 A Minimum load: +5 V @ 0.3 A, +3.3 V @ 0.3 A, +12 V @ 0.2 A MTBF: 100,000 hours @ 25°C, full load Safety: UL/CSA/TUV/FCC/CE/CB/CCC Dimension of IPC-7220 Figure 1.1 Dimensions of IPC-7220 IPC-7220 User Manual...

  • Page 11: Chapter 2 System Setup

    Chapter System Setup This chapter introduces the instal- lation process. Sections include: ! Remove the Cover ! Installing a Motherboard ! Adding Disk Drives ! Installing Plug-in Cards ! Bi-Directional Mounting...

  • Page 12: Removing The Cover

    The following procedures are provided to assist you in installing a motherboard, drives, and plug-in cards into the IPC-7220. Please also refer to the Appendix A, Exploded Diagram, for the parts naming in this manual. Removing the Cover To remove the cover of the IPC-7220, please refer to Figure 2.1.

  • Page 13: Installing A Motherboard

    Installing a Motherboard The IPC-7220 accepts both ATX and microATX motherboard. To install a mother- board, refer to Figure 2.2 and proceed as follows: Note! To avoid any component interfering between a motherboard and the chassis and to ensure the best air flow inside the chassis, it is highly rec- ommended to choose a CPU cooler which is lower than 70 mm.

  • Page 14: Adding Disk Drives

    Figure 2.3 Installing the drives Installing plug-in cards The IPC-7220 can accept up to seven plug-in cards. To install a plug-in card, please refer to Figure 2.4 and proceed as follows: Remove the two screws, which mount the hold-down clamp to the chassis, then take out the hold-down clamp.

  • Page 15: Bi-Directional Mounting

    Figure 2.4 Hold-down clamp installation Bi-directional mounting Attached the IPC-7220 with two mounting brackets to the bottom or right side of the chassis (see Figure 2.5). These special mounting brackets allow you to mount the chassis onto most surfaces, such as wall, panel, work bench, underneath or on top of a desk or table.
  • Page 16 IPC-7220 User Manual...

  • Page 17: Chapter 3 Operation

    Chapter Operation This chapter introduces the sys- tem operation information. Sections include: ! The Front Section of IPC-7220 ! Replacing the Fan ! Replacing the Filters ! Replacing the Power Supply...

  • Page 18: The Front Section Of Ipc-7220

    The Front Section of IPC-7220 3.1.1 Switches Behind the drive bay door, three switches are used for system power on-off, system reset and alarm reset. Power On-Off Switch: Use this switch to turn on/off the system power. System Reset Switch: Press this switch to reinitialize the system.

  • Page 19: Replacing The Fan

    Replacing the Fan There is one fan below the drive bay of IPC-7220. To change the fan, refer to Figure 3.1 and proceed as follows: Un-plug the fan power connector. Remove the two screws, which mount the fan bracket to the chassis and lift it with two fingers.

  • Page 20: Replacing The Filters

    Replacing the filters There are two filters in the IPC-7220, one in front of the fan and the other in the drive bay door. To change the filters, located at the front end of the chassis, and proceed as follows: 3.3.1...

  • Page 21: Replacing The Power Supply

    Replacing the power supply IPC-7220 supports both 300W PS/2 and 300W redundant power supply. To change the power supply, refer to Figure 3.3 and proceed as follows: Un-plug the AC inlet from the power supply of IPC-7220. Remove the cover of IPC-7220.
  • Page 22 IPC-7220 User Manual...

  • Page 23: Chapter 4 Alarm Board

    Chapter Alarm Board This chapter introduces the alarm board and thermal sensor specifi- cations. Sections include: ! Alarm Board Layout ! Alarm Board Specifications ! Switch Settings ! Thermal Sensor...

  • Page 24: Alarm Board Layout

    One voltage signal connector (connect from back plane, includes 12V, ± ± 3.3V) – One Hard Disk LED connector (connect from CPU card) Output Signals: – One LED board connector – One LCM board connector – One Buzzer output IPC-7220 User Manual...
  • Page 25 Pin 1 Pin 2 SOUT Pin 3 CTS# Pin 4 DCD# Pin 5 RTS# Pin 6 DTR# Pin 7 DSR# Pin 8 ID 0 Pin 9 ATX ON Pin 10 DO 4 Pin 11 Pin 12 DO 3 IPC-7220 User Manual...
  • Page 26 Pin 1 5VSB Pin 2 Pin 3 Pin 4 Pin 5 Pin 6 +3.3V Pin 7 -12V Pin 8 +12V CN16: 4 bit Power Good Input Pin 1 Power Good A Pin 2 CN18: LED Board Connector IPC-7220 User Manual...

  • Page 27: Switch Settings

    Pin 5 Watchdog IN Pin 6 Watchdog OUT J1: External Speaker Pin 1 Buzzer Pin 2 Switch Settings 4.3.1 FAN Number Setting Table 4.2: SW1, Fan number setting Fan Number SW 1-1 SW 1-2 SW 1-3 SW 1-4 IPC-7220 User Manual...

  • Page 28: Thermal Board Temperature Setting

    When the temperature rises, the temperature sensor sends a signal to the alarm board and a continuous alarm will sound. To stop the alarm, press the Alarm Reset Switch on the Front Panel. Thermal Sensor Figure 4.2 Thermal sensor IPC-7220 User Manual...

  • Page 29: Exploded Diagram And Parts

    Appendix Exploded Diagram and Parts List...

  • Page 30: Exploded Diagram

    Exploded Diagram Figure A.1 Exploded diagram IPC-7220 User Manual...
  • Page 31 Alarm Board Door Filter Clamp Screw Top Cover Door PCI Guide Rail PS Bracket Fan Bracket Key Set Hinge Support 18 Plastic Door Window Power Holder 19 Rubber Door Hinge 9-Pin Cover Drive Bay Sup- Window port Support IPC-7220 User Manual...
  • Page 32 IPC-7220 User Manual...

  • Page 33: Optional Backplanes

    Appendix Optional Backplanes Sections include: ! Motherboard Options...

  • Page 34: Motherboard Options

    Motherboard Options The IPC-7220 supports a variety of Advantech ATX/MicroATX motherboards described below. Contact a local sales representative for more detailed information. Table B.1: ATX motherboard options Model Name PCI/ISA SATA 1 (PCIe x16) AIMB-764 1 (PCIe x4) 5 (PCI 32-bit)
  • Page 35 IPC-7220 User Manual...
  • Page 36 No part of this publication may be reproduced in any form or by any means, electronic, photocopying, recording or otherwise, without prior written permis- sion of the publisher. All brand and product names are trademarks or registered trademarks of their respective companies. © Advantech Co., Ltd. 2009...
