1.2 Specifications

Construction: Heavy-duty steel
Disk drive capacity: two 3.5" (one front accessible and one
internal) and two 5.25" bays
I/O interfaces on front panel: two USB and one PS/2 ports
I/O interfaces on rear panel: two D-SUB 9-pin openings
Indicators on front panel: LEDs for Power, HDD, TEMP
and FAN
Switches on front panel: Power and Reset
Air filters: one 7 cm x 12 cm filter in drive bay door and
one 12 cm x 12 cm filter
Weight: 11.5 Kg (25.3 lb) with PS-300ATX-ZB power
supply
Dimensions: 200 mm (W) x 320 mm (H) x 480 mm (D)
(6.8" x 12.4" x 18.9")

1.3 Environmental Specifications

Temperature:
(Operating) 0 to 40°C (32 to 104°F)
(Non-operating) -20 to 60°C (-4 to 140°F)
Humidity:
(Operating) 10 to 85% @ 40°C, non-condensing
(Non-operating) 10 to 95% @ 40°C, non-condensing
Vibration (5 ~ 500 MHz): (Operating) 1G rams
Shock:
(Operating) 10G with 11 ms duration, half sine wave
(Non-operating) 30G
(Non-operating) 2G rams
3
