8. REGULATION

8.1. Adjusting the lower portafilter support
In order to ensure the proper distribution of ground coffee in the portafilter, while
supporting the portafilter in a hands-free position during dosing, it is possible to
adjust the height of the lower portafilter support (
1.
Loosen the two adjustment screws (
portafilter fork (
2.
Adjust the support to the desired height using the portafilter as the point of
reference.
3.
Tighten the screw (
the Allen Key provided (Fig. 1).
NOTE: If the adjustment is extreme (too high or too low), difficulties in operating
the dosis button might occur.
K06315 | v. 19/07/2016 | Ref. quality process 002/03 | ORIGINAL INSTRUCTIONS
), by using the Allen Key included with your grinder.
) found on each side of the upper portafilter fork (
).
) found on each side of the upper
), with
