i3 Touch
COFFEE GRINDER
USER MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the i3 Touch and is the answer not in the manual?

Questions and answers

Related Manuals for Compak i3 Touch

Summary of Contents for Compak i3 Touch

  • Page 1 Touch COFFEE GRINDER USER MANUAL...
  • Page 2 K09659H01 | PROC-CAL/002/03 USER MANUAL | V. 06/09/2023...

  • Page 3: Table Of Contents

    CONTENTS i3 Touch COFFEE GRINDER SAFETY DESCRIPTION INSTRUCTIONS IDENTIFICATION TECHNICAL CHARACTERISTICS EXTERNAL COMPONENTS INSTALLATION ADJUSTMENT OPERATION CLEANING MAINTENANCE DECLARATION OF CONFORMITY K09659H01 | PROC-CAL/002/03 USER MANUAL | V. 06/09/2023...

  • Page 4: Safety

    SAFETY ADDITIONAL SAFETY MEASURES BUILT-IN TO OUR GRINDERS: Special screw to keep the hopper fixed. • This coffee grinder Children should not should only be used play with the device. for the function for which it was designed: Cleaning and grinding coffee beans.
  • Page 5 SAFETY USERS SHOULD PAY SPECIAL ATTENTION TO, AND SCRUPULOUSLY OBEY THE FOLLOWING SAFETY INSTRUCTIONS If it is necessary to access the interior, where the electrical components are located, go to the nearest technical service Any other use will be considered improper In the event of and dangerous.

  • Page 6: Description

    For the optimum functionality of the grinder models described in this user manual, the maximum work cycles are as follows: Icons: Information Warning Work cycle Model i3 Touch 24sec 1min SOUND LEVEL The level of sound emitted is: Sound level With coffee i3 Touch 78,5 dB K09659H01 | PROC-CAL/002/03 USER MANUAL | V.

  • Page 7: Identification

    IDENTIFICATION TECH. CHARACTERISTICS 5.1. SCOPE technical characteristics The coffee grinders are intended for commercial plate is indelibly marked with the applications where ground coffee must be following information: used, or in small shops selling coffee, but not for continuous mass production of food. This grinder should only be used to grind coffee beans.

  • Page 8: External Components

    EXTERNAL COMPONENTS Hopper security screw Hopper Coffee bean hopper Hopper shutter Grind regulator Position indicator Upper portafilter holder Exit chute Dose button Portafilter holder Timer Switch 3 positions Coffee collection tray K09659H01 | PROC-CAL/002/03 USER MANUAL | V. 06/09/2023...

  • Page 9: Installation

    Model i3 Touch regulations. 7.2. IMPORTANT WARNINGS Height The operator must be a responsible adult. Width Never a child nor someone without the ability to accept that responsibility.

  • Page 10: Adjustment

    ADJUSTMENT 8.1. GRINDER SET UP Remove the hopper lid ( ), fill the hopper with coffee ( ), and replace the lid on the hopper ) (Fig. 3). Place the hopper ( ) on the grind regulator ) and make sure the bean trap ( ) is in the closed position (Fig.
  • Page 11 ADJUSTMENT 8.2. ADJUSTING THE TOP 8.3. GRIND ADJUSTMENT SYSTEM PORTAFILTER SUPPORT Rotate the grind regulator ( ) until reaching the In order to ensure the proper distribution of grind level desired. ground coffee in the portafilter, while supporting Rotating the grind regulator clockwise will result the portafilter in a hands-free position during in a courser grind;...

  • Page 12: Operation

    I / 0 / II (Fig. 7) To adjust the grind time, simply turn the timer ) found on the front of the grinder (Fig. knob ( i3 Touch 6). Turning clockwise will increase the grind time, and turning the knob counterclockwise Timed Grind.

  • Page 13: Cleaning

    10.1. GENERAL CLEANING 10.3. CLEANING THE GRIND CHAMBER 10.3.1 Compak recommends that the grind 10.1.1 To ensure that the grinder functions chamber be cleaned monthly with a cleaner . properly, and produces the highest quality grind This process will eliminate smelly residues from...

  • Page 14: Maintenance

    CLEANING MAINTENANCE 10.4. CLEANING THE OUTSIDE OF THE 11.1. GENERAL WARNING GRINDER 11.1.1 Before performing any type of 10.4.1 To clean the exterior of the grinder, first maintenance you should: wipe with a dry soft cloth, and then gently wipe with a damp cloth and neutral soap.
  • Page 15 MAINTENANCE 11.3. GRINDING GROUP MAINTENANCE 11.3.3 Loosen the grinding regulator screws using an Hex Allen screwdriver #3, according to (Fig.3). Remove the regulator by pulling up. To perform grind chamber maintenance please (Fig.4). observe the following steps: 11.3.1 Turn off the grinder by making sure the ) is on the OFF position.
  • Page 16 MAINTENANCE 11.3.5 When reassembling the regulator, 11.4.2 Using a Hex Allen key #3, loosen match the point 0 close to the position indicator the two screws of the coffee exit chute and (Fig. 7) and tight the screws back on. remove it from the grinder body to gain access to the metal grid (Fig.

  • Page 17: Declaration Of Conformity

    Compak Coffee Grinders, s.a. Molí Barri, Parcela B - Pol. Ind. Can Barri - 08415 Bigues i Riells - Barcelona - Spain Ph. 34 93 703 13 00 - www.compak.es - info@compak.es K09659H01 | PROC-CAL/002/03 USER MANUAL | V. 06/09/2023...
  • Page 18 K09659H01 | PROC-CAL/002/03 USER MANUAL | V. 06/09/2023...
  • Page 19 K09659H01 | PROC-CAL/002/03 USER MANUAL | V. 06/09/2023...
  • Page 20 www.fsc.org USER MANUAL K09659H01 | PROC-CAL/002/03 | v.19/06/2023...
