Canon ImagePrograf iPF840 series Basic Manual page 27

iPF840 Series
When inserted, sheets are automatically held by suction against the Platen.
•
Load a sheet so that it is parallel to the Paper Alignment Line at right (c). Loading paper askew will
cause an error.
Important
•
Warped paper may rub against the Printhead. Straighten paper if it is warped before loading it.
•
You can adjust the strength of suction holding paper against the Platen when the Release Lever is up. If it
is difficult to load paper, press the ▲ or ▼ button on the Control Panel to adjust the strength. Set suction
Note
stronger by pressing the ▲ button or weaker with the ▼ button. Three settings are available.
However, even if you increase the suction, it may not be sufficient to hold some types of paper against
the Platen well. In this case, use your hand to load the paper.
•
Sheets are held in place by suction through holes on the Platen. Although the suction may produce a
noise when paper is loaded in some positions, it does not indicate a problem. If the noise is distracting,
try moving the paper over slightly to the left or right (up to 1 mm [0.039 in]) while keeping it parallel to the
Paper Alignment Line.
•
The suction remains on for about 30 seconds during loading. If you cannot finish loading a sheet during
this time, pull the sheet away and reinsert it to start the suction again.
4
Lower the Release Lever and close the Top Cover.
• If a print job was received
Pressing the OK button will advance the paper, and then printing will begin.
• If no print job was received
A menu for selection of the type of paper is shown on the Display Screen.
Press ▲ or ▼ to select the type of paper, and then press the OK button.
The printer now starts feeding the paper.
•
Refer to Paper Reference Guide for details on type of paper to select. (See "Displaying the Paper Refer-
ence Guide.")
Note
Basic Guide
User's Guide
➔
Loading Sheets in the Printer
27
