iPF840 Series
6
Remove the Printhead and press the OK button.
•
Never touch the metal contacts of the Carriage. Furthermore, do not allow any dirt or debris to become
adhered to the metal contacts of the Carriage. These may damage the printer.
Important
•
Dispose of the used Printhead in accordance with local regulations.
Note
7
Holding the new Printhead by the grips (a), remove it from
the pouch.
•
When handling the Printhead, always hold it by the grips (a). Never touch the nozzles (b) or metal con-
tacts (c). This may damage the Printhead and affect printing quality.
Important
• Never touch the ink supply section (d). This may
cause printing problems.
8
While firmly holding the Printhead you have removed, use
your other hand to remove the orange Protective Part (a).
Squeeze the grips (c) of Protective Part (b) and pull it down to
remove it.
Basic Guide
a
a
d
c
b
d
a
b
Replacing the Printhead
a
c
43
