Fuses - Can-Am outlander 400 series Operator's Manual

WARNING
Connect RED (+) cable first then
BLACK (-) cable. Always connect
RED (+) cable first.

Fuses

WARNING
Always turn the ignition switch to
OFF position before replacing a de-
fective fuse.
If a fuse is damaged, replace it by one
of the same rating.
CAUTION: Do not use a higher rat-
ed fuse as this can cause severe
damage.
Fuses are located in the service com-
partment.
TYPICAL
1. Fuse holders
While reading this Operator's Guide, remember that:
Indicates a potential hazard that, if not avoided, could result in serious in-
jury or death.
_____________________
132
vmo2006-005-029_a
1. Accessories (15 A) (power outlet and
auxiliary supply)
2. Fan (20 A)
3. Main (30 A)
4. Charging system (20 A)
To remove fuse from holder, remove
the fuse holder cover then pull fuse
out. Check if filament is melted.
TYPICAL
1. Fuse
2. Check if melted
WARNING
