Can-Am MAVERICK X3 Series 2017 Operator's Manual
  1. Manuals
  2. Brands
  3. Can-Am Manuals
  4. Offroad Vehicle
  5. MAVERICK X3 Series 2017
  6. Operator's manual

Can-Am MAVERICK X3 Series 2017 Operator's Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

2017
Operator's
Guide
Includes
Safety, Vehicle

Maintenance Information

and
MAVERICK
X3 Series
TM
WARNING
Read this guide thoroughly. It contains important safety information.
Minimum age: Operator: 16 or older with a valid driver's license. Keep this Operator's Guide in the vehicle.
Original Instructions

Advertisement

Table of Contents
loading

Related Manuals for Can-Am MAVERICK X3 Series 2017

Summary of Contents for Can-Am MAVERICK X3 Series 2017

  • Page 1: Maintenance Information

    2017 Operator’s Guide Includes Safety, Vehicle Maintenance Information MAVERICK X3 Series WARNING Read this guide thoroughly. It contains important safety information. Minimum age: Operator: 16 or older with a valid driver’s license. Keep this Operator’s Guide in the vehicle. Original Instructions...
  • Page 2 In Canada, products are distributed by Bombardier Recreational Products Inc. (BRP). In USA, products are distributed by BRP US Inc. The following trademarks are the property of Bombardier Recreational Products Inc.: Can-Am ® DPS™ ROTAX ® XPS™...

  • Page 3: Foreword

    It's backed by the BRP limited warranty Failure to follow the warnings con- and a network of authorized Can-Am tained in this Operator's Guide can dealers ready to provide the parts, ac- result in SERIOUS INJURY or DEATH.

  • Page 4: About This Operator's Guide

    FOREWORD CAUTION Indicates haz- ardous situation which, if not avoided, could result in minor or moderate injury. NOTICE Indicates an instruction which, if not followed, could result in severely damaged vehicle com- ponents or other property. About this Operator's Guide This Operator's Guide has been pre- pared to acquaint the owner/operator of a new vehicle with the various ve-...

  • Page 5: Table Of Contents

    TABLE OF CONTENTS FOREWORD ................1 Know Before you Go .
  • Page 6 TABLE OF CONTENTS PRIMARY CONTROLS (cont’d) 3) Brake Pedal ..............41 4) Shift Lever .
  • Page 7 TABLE OF CONTENTS BASIC PROCEDURES (cont’d) Choosing the Correct Range (Low or High) ........71 Stopping the Engine and Parking the Vehicle .
  • Page 8 MESSAGES IN MULTIFUNCTION GAUGE ........126 WARRANTY BRP LIMITED WARRANTY USA AND CANADA: 2017 CAN-AM ®...

  • Page 9: Safety Information

    SAFETY INFORMATION ________ ________ SAFETY INFORMATION...

  • Page 10: General Precautions

    Other Hazards crease risk of a crash. Gasoline is extremely flammable and See your authorized Can-Am dealer for highly explosive. Fuel vapors can available accessories for your vehicle. spread and be ignited by a spark or flame many feet away from the en- gine.

  • Page 11: Safe Operation - Responsibilities

    Take a training course if available (con- vehicle. Consider supervising new or tact an authorized Can-Am dealer to young operators and setting rules and find out about training course avail- limits (e.g., whether they can carry a...

  • Page 12: Riding Carefully

    SAFE OPERATION - RESPONSIBILITIES Never use this vehicle with drugs or al- – Never attempt skidding or sliding. cohol, or if tired or ill. These slow reac- If vehicle starts to skid or slide, tion time and impair judgment. counter steer in the direction of skidding or sliding.
  • Page 13 SAFE OPERATION - RESPONSIBILITIES – Never operate excessively – Always ensure to properly park the rough, slippery or loose terrain un- vehicle on the flattest terrain section til you have learned and practiced available. Put shift lever in PARK, the skills necessary to control this stop engine and remove key before vehicle on such terrain.

  • Page 14: Pre-Ride Inspection

    PRE-RIDE INSPECTION Always inspect and confirm the safe operating condition of your vehicle prior to ride. Always follow the maintenance schedule described in this Operator's Guide. WARNING Perform a pre-ride inspection before each ride to detect any potential prob- lem that could occur during operation. The pre-ride inspection can help you monitor component wear and deterioration before they become a problem.
  • Page 15 PRE-RIDE INSPECTION ITEMS ✔ TO BE INSPECTION TO PERFORM INSPECTED Engine air Inspect engine air filter, replace if needed. filter Inspect airbox and clean if necessary (when riding in dusty conditions Airbox or sand). CVT air filter Inspect and clean the CVT air filter (when riding in dusty conditions). Drive shaft Check drive shaft boots condition.
  • Page 16 PRE-RIDE INSPECTION ITEMS TO BE ✔ INSPECTION TO PERFORM INSPECTED Check seat adjustment and make sure locking device is properly engaged before riding. Check doors for any damage. Have the doors replaced if any damage is found. Seats, doors and Close both doors and confirm that they latch seat belts securely.

  • Page 17: Prepare To Ride

    PREPARE TO RIDE Before you Ride Weather conditions should help you decide how to dress. To maximize Perform pre-ride inspection to confirm comfort and avoid frostbites in win- the safe operating condition of your ve- ter, dress for the coldest weather ex- PRE-RIDE INSPECTION hicle.
  • Page 18 PREPARE TO RIDE Use tinted face shields or goggles in crash, good quality protective gear the daytime only; do not use them at made of sturdy material may prevent night or in poor illumination. Do not or reduce injury. use them if they impair your ability to In cool-weather riding, protect your- discern color.

  • Page 19: Avoid Accidents

    AVOID ACCIDENTS Avoid Rollovers and – Never attempt donuts, skids, slides, fishtails, jumps, or other stunts. If Tipovers vehicle starts to skid or slide, steer Side-by-side vehicles handle differ- in the direction of the skid or slide. ently from other vehicles. Side-by-side Never slam the brakes and lock the vehicles are designed to handle wheels.

  • Page 20: Avoid Collisions

    AVOID ACCIDENTS – Never grab the cage while riding. Hands can be crushed between the cage and the ground in a rollover. Keep hands on the steering wheel or handholds. – Never try to stop a rollover using your arms or legs. If you think that the vehicle may tip or roll, the driver should keep both hands on the steering wheel and the left foot...

  • Page 21: Riding Your Vehicle

    RIDING YOUR VEHICLE Practice Exercises U Turn Exercises Before you go out for a ride, it is very Practice doing U turns. important to familiarize yourself with – Accelerate slowly and while remain- the handling of your vehicle by prac- ing at low speed, then gradually turn ticing in a controlled environment.

  • Page 22: Off-Road Operation

    Never operate the vehicle if the con- trols do not function normally. See an The very nature of off-road operation authorized Can-Am dealer. is dangerous. Any terrain, which has not been specially prepared to carry To maintain proper control it is strongly...
  • Page 23 RIDING YOUR VEHICLE NOTE: In reverse operation, the en- ilarly so, be watchful of hazards such gine RPM is limited thus limiting the as rocks, logs, etc., partially covered by vehicle reverse speed. vegetation. Riding on Snow or Ice WARNING When performing pre-ride inspection, When driving downhill in reverse, pay special attention to locations on...
  • Page 24 RIDING YOUR VEHICLE keep brake and accelerator pedals and Riding on Gravel, Loose Stones or floor boards free of snow and ice. Fre- Other Slippery Surfaces quently wipe snow off seat, steering Riding on loose stones or gravel is very wheel, headlights and tail lamps.
  • Page 25 RIDING YOUR VEHICLE pery or has too loose a surface, you Side Hilling can lose control. If you go over the Whenever possible, sidehilling (driv- top of a hill at high speed, you may not ing across a slope rather than up or have time to prepare for the terrain down it) should be avoided.
  • Page 26 RIDING YOUR VEHICLE club does not exist in your area, help hicle. If you encounter animals on the to start one. Group riding and club ac- trail, stop and observe quietly and with tivities provide a pleasurable, social caution. It will be one of the better experience.

  • Page 27: Moving Loads And Doing Work

    Your vehicle can help you perform a number of different LIGHT tasks ranging from snow removal to carrying cargo. A variety of accessories are available from your authorized Can-Am dealer. To prevent possible injury, follow the instructions and warnings that accompany the accessory. Always respect the load limits of the vehicle.
  • Page 28 MOVING LOADS AND DOING WORK NOTE: When carrying heavy loads in WARNING cargo rack or pulling a loaded trailer Never overload, tow or carry cargo operate with the shift lever in L (low improperly. Safely reduce speed range). according to terrain conditions when carrying cargo or pulling a Loading the Cargo Rack trailer, and avoid hills and rough...
  • Page 29 MOVING LOADS AND DOING WORK ing, especially on inclined surfaces Use caution when disconnecting a and when a passenger is on board. Be loaded trailer; it or its load may topple careful not to skid or slide. on you or others. When hauling a trailer, respect the ma- Pulling a Trailer ximum hauling capacity indicated on...

  • Page 30: Important On-Product Labels

    The following labels are on your vehi- cle, and they should be considered per- manent parts of the vehicle. If missing or damaged, they can be replaced free of charge. See an authorized Can-Am dealer. _______ ________ SAFETY INFORMATION...
  • Page 31 IMPORTANT ON-PRODUCT LABELS 219001761-003_b ________ ________ SAFETY INFORMATION...
  • Page 32 IMPORTANT ON-PRODUCT LABELS EN-704906372-DEC LABEL 1 _______ ________ SAFETY INFORMATION...
  • Page 33 IMPORTANT ON-PRODUCT LABELS Improper Use of Off-Highway Vehicles Can Cause Severe Injury or Death Be prepared in case of rollover • Hold the cage while riding. • Try to stop a rollover using your arm or leg. • Fasten seat belts and close doors. Require Proper Use of Your Vehicle Do your part to prevent injuries: •...
  • Page 34 IMPORTANT ON-PRODUCT LABELS PASSENGER Improper Use of Off-Highway Vehicles Can Cause Severe Injury or Death Be prepared in case of rollover • Hold the cage while riding. • Try to stop a rollover using your arm or leg. • Fasten seat belts and close doors. Be Prepared •...
  • Page 35 IMPORTANT ON-PRODUCT LABELS Put the Shift Lever to PARK (P) before exiting vehicle. The vehicle can roll if not in PARK. Stop the vehicle and apply the Brake before using the Shift Lever and the 2WD/4WD Switch. EN-704906152-DEC LABEL 4 Improper tire pressure or overloading can cause loss of control.
  • Page 36 IMPORTANT ON-PRODUCT LABELS Overloading can cause loss of control. Loss of control can result in severe injury or death. NEVER exceed the vehicle load capacity of 286 Kg (630lb) including weight of operator, passenger, accessories and trailer tongue weight. NEVER carry passengers on this carrier.
  • Page 37 IMPORTANT ON-PRODUCT LABELS WARNING Storage compartment Maximum load: 5 kg (11 lb) 704906154B EN-704906154-DEC LABEL 9 Get familiar with this Off-Highway Vehicule (OHV); it may exceed the performance of other OHV you may have ridden. This is a high performance OHV. Inexperienced riders may EN-704906157-DEC...
  • Page 38 IMPORTANT ON-PRODUCT LABELS WARNING This vehicle is an off road vehicle not intended for use on public roads. AVERTISSEMENT Ce véhicule est conçu pour un 704906158-DEC usage hors route LABEL 14 et n'est pas destiné aux voies publiques. EN-FR-704906373-DEC LABEL 16 704906159-DEC LABEL 15 _______...

  • Page 39: Compliance Labels

    IMPORTANT ON-PRODUCT LABELS Compliance Labels Technical Information Labels These labels indicate vehicle's compli- ance. 707800373 LOCATION: ON ENGINE AIR FILTER HOUSING COVER 219001761-005_a TYPICAL 1. Compliance labels located behind passenger seat CAN ICES-2/NMB-2 POWER PUISSANCE WET WEIGHT POIDS EN ETAT DE MARCHE 704904561 EMISSION CONTROL INFORMATION...
  • Page 40 IMPORTANT ON-PRODUCT LABELS This page is intentionally blank _______ ________ SAFETY INFORMATION...

  • Page 41: Vehicle Information

    VEHICLE INFORMATION _______________...

  • Page 42: Primary Controls

    PRIMARY CONTROLS It is important to know the location and operation of all controls, and to develop and practice smooth and coordinated use of them. NOTE: Some vehicle safety labels are not shown on illustrations. For information VEHICLE SAFETY LABELS on vehicle safety labels, refer to subsection.

  • Page 43: Accelerator Pedal

    PRIMARY CONTROLS CAUTION Under rough trail conditions or when crossing an ob- stacle, the steering wheel could sud- denly jerk on one side, causing hand or wrist injuries if the thumbs are rolled around the steering wheel. The DPS reduces the effort to turn the steering wheel.
  • Page 44 PRIMARY CONTROLS Park The park position locks the gearbox to help prevent vehicle movement. WARNING Always use the PARK (P) position when the vehicle is not in oper- ation. The vehicle can roll if the shift lever is not set to P (PARK). Reverse The reverse position allows the vehicle to go backwards.

  • Page 45: Secondary Controls

    SECONDARY CONTROLS NOTE: Some vehicle safety labels are not shown on illustrations. For information VEHICLE SAFETY LABELS on vehicle safety labels, refer to subsection. 219001761-015_a 1) RF D.E.S.S Key and RF RF D.E.S.S Key D.E.S.S. Post Digitally Encoded Security System (D.E.S.S.) RF D.E.S.S.

  • Page 46: Engine Start/Stop Button

    SECONDARY CONTROLS 2) Engine Start/Stop WARNING Button Rollovers, tipovers, collisions and The engine start / stop button is located loss of control resulting in seri- on the upper console. When pressed ous injury or death are possible and held, it starts the engine. with the performance or learning keys.

  • Page 47: 2Wd/4Wd Switch

    SECONDARY CONTROLS 4) 2WD/4WD Switch The 2WD/4WD switch is located on the upper console. 219001761-076_d TYPICAL 1. Sport/ECO switch The sport mode provides a crisper throttle response. 219001761-076_e NOTE: The sport mode can be acti- TYPICAL vated with all key types and provides 1.

  • Page 48: Dps Switch

    SECONDARY CONTROLS 7) DPS Switch The override switch main functions are: The DPS switch is used to change the 1. To bypass the engine speed limiter DPS (Dynamic Power Steering) mode. in reverse operation by allowing ma- To change mode, DPS switch needs to ximum engine torque be held for at least 2 seconds.

  • Page 49: Multifunction Gauge (Analog/Digital)

    MULTIFUNCTION GAUGE (ANALOG/DIGITAL) Multifunction Gauge Description The multifunction gauge (analog/digital) is located on the steering column. The multifunction gauge (analog/digital) is comprised of a digital gauge and two analog gauges (speedometer and tachometer). The engine temperature and fuel level bar graphs are comprised in the digital gauge.
  • Page 50 MULTIFUNCTION GAUGE (ANALOG/DIGITAL) 1) Analog Speedometer Measures vehicle speed in km/h or mph. 2) MODE (M) Button Pressing the MODE (M) button will scroll through the functions of the main digital display. FUNCTION SEQUENCE OPTIONS Press SET (S) to scroll and select desired Numerical Display is flashing function and press MODE (M) to confirm Press SET (S) to scroll and select desired...
  • Page 51 MULTIFUNCTION GAUGE (ANALOG/DIGITAL) 5) Indicator Lamps Indicator lamps will inform you of various conditions or problems. An indicator lamp can flash alone or in combination with another lamp. INDICATOR LAMP(S) DESCRIPTION All indicator lamps are activated when D.E.S.S. key All indicator lamps is installed and the engine is not started Low fuel Check engine...
  • Page 52 MULTIFUNCTION GAUGE (ANALOG/DIGITAL) MESSAGE DESCRIPTION Message displayed when the brakes are applied continuously for BRAKE 15 seconds. (Speed needs to be higher than 5 km/h (3 MPH)) PERFORMANCE Displayed at power up when the performance key is used. Displayed at power up when the normal key is used. LEARNING KEY WORK KEY Displayed at power up when the work key is used.

  • Page 53: Gauge Setup

    For display function informa- SET (S) BUTTON tions, refer to Gauge Setup Setting Metric/Imperial Units See a Can-Am dealer for adjustments. Setting Clock 1. Press MODE (M) button to select clock display. 2. Push and hold MODE (M) button for three seconds.

  • Page 54: Equipment

    EQUIPMENT NOTE: Some vehicle safety labels are not shown on illustrations. For information VEHICLE SAFETY LABELS on vehicle safety labels, refer to subsection. 219001761-131_a TYPICAL ______________...

  • Page 55: Tilt Steering

    EQUIPMENT 219001761-130_a TYPICAL 1) Tilt Steering The steering wheel height is ad- justable. Adjust the steering wheel height to face your chest, not your head. To adjust steering wheel height: 1. Unlock steering by pulling the tilt lever toward you. 219001761-017_a 2.

  • Page 56: Passenger Handholds

    EQUIPMENT 4) Glove Box The vehicle is equipped with a closed glove box made to carry light objects. 219001761-018_a TYPICAL 1. Cup holders NOTE: Do not use cup holders while riding in rough conditions. 219001761-067_a 1. Glove box 3) Passenger Handholds There is one passenger handhold on GLOVE BOX CAPACITY the console and one in the RH door.

  • Page 57: Doors

    EQUIPMENT 8) Seat Belts Always wear appropriate footwear. RIDING GEAR subsection. This vehicle is equipped with seat belts to help protect driver and passenger in 7) Doors the event of collisions, rollovers, or tipovers to help keep passengers in Vehicle is equipped with doors to help the cockpit.

  • Page 58: Driver's Seat

    EQUIPMENT WARNING WARNING There is no indicator light or mes- Wear seat belt properly. Make sure sage for the passenger seat belt. it remains securely fastened and The driver is responsible for the tightened against the body. Make passenger safety and should en- sure it is not twisted or defective.
  • Page 59 EQUIPMENT Setup in HIGH Position Remove both retaining nuts securing rear adjustment mechanism assem- blies. Remove both retaining nut securing front adjustment mechanisms in place. Assemble both rear adjustment mech- anisms as follows. tmr2017-049-004_a Seat Height Adjustment Seat height can be adjusted. 219001761-033_a REAR ADJUSTMENT MECHANISM IN POSITION HIGH...

  • Page 60: Passenger Seat

    EQUIPMENT WARNING Ensure both mechanisms at the front and both mechanisms at the rear are set to the same position (HIGH or LOW) before riding the vehicle. Tighten both nuts to specification. TIGHTENING TORQUE 219001761-035_a FRONT ADJUSTMENT MECHANISM IN Rear 105 N•m ±...

  • Page 61: Fuel Reservoir Cap

    EQUIPMENT The passenger seat can be removed by removing retaining nuts securing SEAT HEIGHT seat to frame. Refer to ADJUSTMENT The seat cushion can easily removed, SEAT CUSHION REMOVAL refer to AND INSTALLATION for procedure. 11) Fuel Reservoir Cap Open fuel reservoir cap cover. 219001761-027_a CARGO RACK WARNING...

  • Page 62: Wheel Scraper

    EQUIPMENT 15) 12-Volt Power Outlet Convenient for handheld spotlight or other portable equipment. 219001761-125_a 1. Rear recovery hook 14) Wheel Scraper Located inside the rear wheels to 219001761-014_a reduce accumulation of mud in the 1. 12 V power outlet wheels that can damage parts inside the wheels.
  • Page 63 EQUIPMENT 219001761-056_a 1. Central mirror _______________...

  • Page 64: Tune Your Ride

    TUNE YOUR RIDE Suspension Adjustment Adjustment Location Guidelines Your vehicle handling and comfort de- pend upon suspension adjustments. WARNING Suspension adjustment could af- fect vehicle handling. Always take time to familiarize yourself with the vehicle's behavior after any suspension adjustment has been made.

  • Page 65: Suspension Factory Settings

    TUNE YOUR RIDE 219001761-040_b 219001761-041_a TYPICAL - MAVERICK X3 X DS AND X RS TYPICAL - MAVERICK X3 X RS MODELS - MODELS - FRONT SUSPENSION REAR SUSPENSION 1. Compression damping (high speed and low 1. Compression damping (high speed and low speed) speed) 2.

  • Page 66: Suspension Adjustments

    TUNE YOUR RIDE FRONT SUSPENSION FACTORY SETTINGS ADJUSTMENT MODEL FACTORY SETTING Maverick X3 X ds Position 12 Rebound damping Maverick X3 X rs Position 12 Maverick X3 122.8 mm (4.83 in) Crossover ring position Maverick X3 X ds 120 mm (4.72 in) Maverick X3 X rs 71 mm (2.8 in) REAR SUSPENSION FACTORY SETTINGS...
  • Page 67 TUNE YOUR RIDE Lift the vehicle. Spring length should be measured without load on the wheels. Spring length should be equal on both sides. Adjust by loosening lock ring and turn- ing adjuster ring as desired. Use tool from vehicle tool kit. 219001682-007_a NOTE: Do not increase the front/rear 1.
  • Page 68 TUNE YOUR RIDE Low Speed Compression Damping RESULT ON ACTION (Maverick X3 X ds and Maverick X3 SMALL BUMPS X rs) Increasing Firmer Low speed compression damping con- high speed compression trols how the shock absorber reacts to compression damping (fast a low suspension velocity (slow com- damping force compression)

  • Page 69: Dps Function

    TUNE YOUR RIDE Adjusting Spring Crossover Dual compression rate crossover point can be modified by adjusting the crossover rings position. See an au- thorized Can-Am dealer. 219001761-076_f 1. DPS switch 2. Check the multifunction gauge to confirm the active DPS mode.

  • Page 70: Fuel

    FUEL Fuel Requirements Use of fuel labeled E15 is prohibited by U.S. EPA Regulations. NOTICE Always use fresh gaso- line. Gasoline will oxidize; the re- Vehicle Fueling Procedure sult is loss of octane, volatile com- pounds, and the production of gum WARNING and varnish deposits which can damage the fuel system.

  • Page 71: Fueling A Gasoline Container

    FUEL WARNING Never top up the fuel tank before placing the vehicle in a warm area. As temperature increases, fuel ex- pands and may overflow. 9. Fully tighten fuel reservoir cap clock- wise until you hear a clicking noise. 219001761-025_a WARNING 1.

  • Page 72: Break-In Period

    BREAK-IN PERIOD Operation During Break-In A break-in period of 10 operating hours or 300 km (200 mi) is required for the vehicle. Engine During the break-in period: – Avoid full throttle operation. – Avoid pressing accelerator pedal more than 3/4 of the stroke. –...

  • Page 73: Basic Procedures

    Some vehicles have the electronic start the engine. drive belt protection function acti- vated. Shifting the Transmission Refer to your authorized Can-Am Apply brakes and select the desired dealer for availability and possible acti- shift lever position. vation. _______________...

  • Page 74: Stopping The Engine And Parking The Vehicle

    BASIC PROCEDURES Stopping the Engine and This function is activated when riding at too slow speed for the high range, Parking the Vehicle such as in the following situations: – Pulling WARNING – Pushing Avoid parking on steep slope as –...

  • Page 75: Tips For Maximizing Drive Belt Durability

    BASIC PROCEDURES Tips for Maximizing Drive Belt Durability Riding style and conditions have a di- rect impact on drive belt durability. Your vehicle features a CVT system de- sign that is optimized to offer the best performance. The CVT and drive belt have successfully endured thousands of miles of durability tests.

  • Page 76: Special Procedures

    CVT. Should the vehicle be rolled over, it will be necessary to have it transported to an authorized Can-Am dealer for in- spection as soon as possible. NEVER START THE ENGINE! Points to be verified, including but not limited to: –...

  • Page 77: Transporting The Vehicle

    TRANSPORTING THE VEHICLE If your vehicle needs to be transported, 3. Remove the key from the D.E.S.S. it should be carried on a flatbed trailer post. of the proper size and capacity. 4. At rear, secure the vehicle on both sides using a strap around the cen- NOTICE Do not tow this vehicle —...
  • Page 78 TRANSPORTING THE VEHICLE WARNING Make sure no loose objects are present inside vehicle during vehi- cle transportation. ______________...

  • Page 79: Lifting And Supporting The Vehicle

    LIFTING AND SUPPORTING THE VEHICLE Front of Vehicle Rear of Vehicle Place vehicle on a flat non slippery Place vehicle on a flat non slippery ground. ground. Ensure vehicle shift lever is set to Activate 4WD mode. PARK. Ensure vehicle shift lever is set to Install an hydraulic jack under the round PARK.
  • Page 80 LIFTING AND SUPPORTING THE VEHICLE This page is intentionally blank ______________...

  • Page 81: Maintenance

    MAINTENANCE _______________...

  • Page 82: Maintenance Schedule

    Can-Am dealer has an in-depth technical knowledge and tools to service the Can-Am SSV, the emission-related warranty is not conditioned on the use of an authorized Can-Am dealer or any other establishment with which BRP has a commercial relationship. For emission-related warranty claims, BRP is limiting...

  • Page 83: Maintenance Schedule

    MAINTENANCE SCHEDULE MAINTENANCE SCHEDULE Make sure to perform proper maintenance at recommended intervals as indicated in the tables. Some items of the maintenance schedule must be performed in function of the calendar, regardless of the distance or time of operation. EVERY YEAR OR 3 000 KM (2,000 MI) OR 100 HOURS (whichever comes first) EVERY YEAR OR 1 500 KM (1,000 MI) OR 50 HOURS (whichever comes first) Check fault codes...
  • Page 84 MAINTENANCE SCHEDULE EVERY YEAR OR 3 000 KM (2,000 MI) OR 100 HOURS (whichever comes first) EVERY YEAR OR 1 500 KM (1,000 MI) OR 50 HOURS (whichever comes first) Inspect rear wheel scrapers wear plates Tighten cage fasteners (if equipped with a replacement cage) Inspect, clean and validate operation of seat belts retractors, buckles and locking tabs Verify coolant level and adjust if needed PERFORM AT THE FIRST 3 000 KM (2,000 MI)AND AT 6 000 KM (4,000 MI)

  • Page 85: Maintenance Procedures

    MAINTENANCE PROCEDURES NOTICE This section includes instructions for When riding in dusty con- basic maintenance procedures. ditions or sand, the airbox needs to be cleaned before every ride. NOTE: Maintenance message can be removed by alternately pressing NOTE: Riding in a group under these the override switch and brake pedal conditions would increase even more 3 times at power up.

  • Page 86: Front Grille Kit

    MAINTENANCE PROCEDURES Front Grille Kit 1. Remove debris from front grille. 2. Clean front grille with water. CVT Air Filters CVT air filter inspection and cleaning frequency should be adjusted accord- ing to riding conditions as it is critical to ensure proper engine performance and life span.

  • Page 87: Engine Oil

    MAINTENANCE PROCEDURES 219001761-204_a 219001761-085_a 1. CVT air filter LH REAR OF VEHICLE 1. Dipstick Step 1: Unlatch Step 2: Lift the rear part Step 3: Pull off 4. Reinstall dipstick, screw it in com- pletely. CVT Air Filter Inspection and 5.
  • Page 88 MAINTENANCE PROCEDURES Recommended Engine Oil RECOMMENDED ENGINE OIL SEASON TYPE XPS 4-STROKE SYNTH. BLEND OIL Summer (P/N 293 600 121) 219001761-208_a XPS 4-STROKE UNDERNEATH REAR OF VEHICLE All seasons SYNTHETIC OIL 1. Magnetic drain plug (P/N 293 600 112) 2. Secondary drain plug NOTE: The XPS oil is specially formu- Clean the drain plugs area.

  • Page 89: Oil Filter

    MAINTENANCE PROCEDURES Install and tighten drain plug to the rec- ommended torque. TIGHTENING TORQUE Secondary 15 N•m ± 2 N•m drain plug (133 lbf•in ± 18 lbf•in) Magnetic 30 N•m ± 3 N•m drain plug (22 lbf•ft ± 2 lbf•ft) OIL FILTER Replace oil filter.

  • Page 90: Radiator

    MAINTENANCE PROCEDURES Install the cover on the engine. Inspect radiator and hoses for leaks or any damage. Tighten oil filter cover screws to rec- ommended torque. Inspect radiating fins. They must be clean, free of mud, dirt, leaves and any TIGHTENING TORQUE other deposit that would prevent the radiator to cool properly.
  • Page 91 MAINTENANCE PROCEDURES 5. Add coolant in system as neces- sary. Use a funnel to avoid spillage. Do not overfill. 6. Reinstall pressure cap on cooling tank. NOTE: Coolant level can be checked by looking at the side of the coolant bottle.
  • Page 92 MAINTENANCE PROCEDURES 219001761-135_a A. 30 cm (12 in) 219001761-095_a 1. Pressure cap Place a drain pan under the lower hose of the radiator. Wait until the coolant flow stops or de- creases. Remove the hose pincher to drain the rest of the coolant. Install radiator hose clamp.

  • Page 93: Muffler Spark Arresters

    MAINTENANCE PROCEDURES 219001761-094_a 219001761-048_a 1. Retaining screws 3. Install pressure cap. 2. Muffler cover 3. Spark arrester 4. Run engine at idle with the pressure cap on until the cooling fan cycles 2 NOTICE Use a soft brush and be times.
  • Page 94 MAINTENANCE PROCEDURES TIGHTENING TORQUE Gearbox oil level 5 N•m ± 0.6 N•m (44 lbf•in ± 5 lbf•in) plug Recommended Gearbox Oil Use the following gearbox oil. RECOMMENDED GEARBOX OIL 219001761-064_a XPS synthetic gear oil (P/N 293 600 140) 1. Gearbox oil level plug NOTE: The XPS oil is specially formu- Reinstall the plug, screw it in com- lated to meet the lubrication require-...

  • Page 95: Spark Plugs

    MAINTENANCE PROCEDURES Spark Plugs Access to Spark Plugs Remove the following parts and fas- teners. 219001761-065_a 1. Gearbox drain plug 2. Engine oil drain plug tmr2017-034-009 Remove rear service cover. tmr2016-106-006_a 1. Magnetic drain plug 2. Sealing ring (discard) 3. Gearbox oil level plug (dipstick) 4.
  • Page 96 MAINTENANCE PROCEDURES tmr2017-034-702_a tmr2017-034-004_a 1. Intercooler assembly 2. Intercooler fan connector Spark Plug Removal 1. Disconnect CAPS (camshaft posi- tion sensor). tmr2017-034-703_a Disconnect intercooler hose tmr2017-019-001_a 2. Remove: – Ignition coil retaining screws – Ground connector. 3. Disconnect ignition coil connectors. tmr2017-034-006 Lift intercooler assembly.

  • Page 97: Cvt Cover

    MAINTENANCE PROCEDURES NOTICE Do not pry on ignition coil TIGHTENING TORQUE with a tool. Ignition coil 9 N•m ± 1 N•m 4. Remove ignition coils with gaskets retaining (80 lbf•in ± 9 lbf•in) from spark plug by rotating coil side screw to side as you pull up.

  • Page 98: Drive Belt

    MAINTENANCE PROCEDURES CVT Cover Removal Loosen CVT inlet hose clamp(s). 219001761-113_a TIGHTENING TORQUE 7 N•m ± 0.8 N•m CVT Cover 219001761-051_a (62 lbf•in ± 7 lbf•in) screws 1. Clamp Use wrench supplied in tool kit to re- Drive Belt move the thirteen CVT cover screws. Drive Belt Removal Remove the center top screw last to support the cover during removal.

  • Page 99: Drive And Driven Pulleys

    This inspection must be performed by proper rotation direction. Install it an authorized Can-Am dealer, repair so that the arrow printed on belt is shop, or person of your own choosing pointing towards front of the vehicle, for maintenance, repair, or replace- viewed from top.

  • Page 100: Battery

    MAINTENANCE PROCEDURES Driven Pulley Battery Cleaning Inspect the bushings of the cam and of Clean battery, battery casing and bat- the sliding sheave of the driven pulley, tery posts using a solution of baking replace worn parts. soda and water. Remove corrosion from battery cable Battery terminals and battery posts using a...

  • Page 101: Lights

    The headlights and taillights are LEDs In the event that a fusible link blows, (Light Emitting Diode). This technol- see a Can-Am SSV dealer, a repair shop ogy has proven itself on the reliability. or the person of your choosing.

  • Page 102: Drive Shaft Boot

    Push and pull the wheels from the up- 219001761-104_a per edge to feel the play. FRONT OF VEHICLE 1. Outer drive shaft boot See an authorized Can-Am dealer, a re- pair shop or person of your choosing if there is abnormal play. ______________...

  • Page 103: Wheels And Tires

    MAINTENANCE PROCEDURES tmr2011-033-002_a 219001761-107_a TYPICAL TYPICAL 1. Direction of rotation Wheels and Tires Tighten wheel lug nuts to the specified torque using the illustrated sequence. Wheel Removal TIGHTENING TORQUE Loosen nuts then lift and support vehi- LIFTING AND SUPPORT- cle. Refer to 120 N•m ±...
  • Page 104 Tire Replacement 1. Tire outer bead Tires replacement should be per- 2. Beadlock inner ring shoulder formed by an authorized Can-Am 2. Install all beadlock screws. To avoid dealer, repair shop or person of your cross threading, start all screws by own choosing.
  • Page 105 MAINTENANCE PROCEDURES TIGHTENING TORQUE Beadlock screws 29 N•m ± 1 N•m (SECOND (21 lbf•ft ± 1 lbf•ft) TORQUE) tmo2015-017-303_a 1. Beadlock to be manually tightened 3. Tighten beadlock screws as per fol- lowing specification and sequence. NOTE: To ensure even pressure on the beadlock clamp ring, tighten screws a few turns at a time.

  • Page 106: Suspensions

    MAINTENANCE PROCEDURES – Check tire position on wheel and reposition it if necessary. – Restart the torquing sequence as detailed. 7. Torque beadlock screws a final time following the indicated sequence. TIGHTENING TORQUE Beadlock 29 N•m ± 1 N•m screws (FINAL 219001761-108_a (21 lbf•ft ±...

  • Page 107: Brakes

    Remove the front service cover. 219001761-112_a TYPICAL - REAR STABILIZER BAR 1. Grease fitting Suspension Inspection See an authorized Can-Am dealer, a re- pair shop or person of your choosing if any problem is detected. 219001761-207_a 1. Front service cover...

  • Page 108: Seat Belts

    Can-Am dealer. Verify the following between visits to your authorized Can-Am dealer: – Brake fluid level – Brake system for fluid leaks – Brake pad wear – Brake cleanliness.

  • Page 109: Vehicle Care

    VEHICLE CARE Post-Operation Care When vehicle is used in salt-water environment rinsing the vehicle with fresh water is necessary to preserve vehicle and its components. Metal- lic parts lubrication is highly recom- mended. Use XPS LUBE (P/N 293 600 016) or an equivalent. This must be performed at the end of each operat- ing day.

  • Page 110: Storage And Preseason Preparation

    4 months, proper storage is a ne- cessity. When using your vehicle after storage, a preparation is required. See an authorized Can-Am dealer, re- pair shop, or person of your own choos- ing to have your vehicle prepared for either storage or the preseason.

  • Page 111: Technical Information

    TECHNICAL INFORMATION ______________...

  • Page 112: Vehicle Identification

    RSS standard(s). Operation is subject of loss. These numbers are required to the following two conditions: (1) this by the authorized Can-Am dealer to device may not cause interference, complete warranty claims properly. and (2) this device must accept any in-...

  • Page 113: Noise Emission Control System Regulation

    NOISE EMISSION CONTROL SYSTEM REGULATION USA and Canada Only Tampering with Noise Control System Is Prohibited! U.S. Federal law and Canadian provincial laws may prohibit the following acts or the causing there of: 1. The removal or rendering inoperative by any person other than for purposes of maintenance, repair or replacement of any device or element of design incorpo- rated into any new vehicle for the purpose of noise control prior to its sale or de- livery to the ultimate purchaser or while it is in use or...

  • Page 114: Ec-Declaration Of Conformity

    The EC-Declaration of Conformity does not appear in this version of the Operator's Guide. Please refer to the printed version that was delivered with your vehicle. ddd2009-001...

  • Page 115: Specifications

    SPECIFICATIONS MODEL ENGINE ® ROTAX 903 Turbo R Engine type 4-stroke, Dual Over Head Camshaft (DOHC), liquid cooled Number of cylinders 12 valves (Adjustment free - Number of valves hydraulic tappets) Bore 74 mm (2.91 in) Stroke 69.7 mm (2.74 in) Displacement 899 cm³...
  • Page 116 SPECIFICATIONS MODEL CVT TRANSMISSION Quick Response System (QRS) CVT Type (Continuously Variable Transmission) Engagement RPM 1800 RPM GEARBOX Dual range (HI-LO) with PARK, Type neutral and reverse Capacity 400 ml (14 U.S. oz) Gearbox oil XPS synthetic gear oil (P/N 293 600 140) Recommended or a 75W 140 API GL-5 ELECTRICAL SYSTEM...
  • Page 117 SPECIFICATIONS MODEL FUEL SYSTEM Fuel delivery Type Electronic fuel injection (EFI) with iTC Throttle body 54 mm with ETA Fuel pump Type Electric (in fuel tank) Idle speed 1250 ± 50 RPM (not adjustable) Premium unleaded gasoline Fuel 91 Pump Posted AKI (95 RON) - Refer FUEL REQUIREMENTS Fuel tank capacity ±...
  • Page 118 SPECIFICATIONS MODEL FRONT SUSPENSION Double suspension arm with Suspension type stabilizer bar Preload adjustment type Threaded Maverick X3 508 mm (20 in) Maverick X3 X ds Suspension travel Maverick X3 X rs 559 mm (22 in) HPG shocks with piggyback reservoir. Maverick X3 QS3†...
  • Page 119 SPECIFICATIONS MODEL BRAKES Dual 262 mm ventilated disc Front brake Type brakes with hydraulic twin-piston calipers (32 mm) Dual 248 mm ventilated disc Rear brake Type brakes with hydraulic twin-piston calipers (28 mm) Capacity 310 ml (10.5 U.S. oz) Brake fluid Type DOT 4 Caliper...
  • Page 120 SPECIFICATIONS MODEL TIRES (cont'd) Maverick X3 28 x 9 x 14 (in) Front Maverick X3 X ds 29 x 9 x 14 (in) Maverick X3 X rs 30 x 10 x 14 (in) Tire size Maverick X3 28 x 11 x 14 (in) Rear Maverick X3 X ds 29 x 11 x 14 (in)
  • Page 121 SPECIFICATIONS MODEL DIMENSIONS (cont"d) Maverick X3 136 cm (53.5 in) Maverick X3 X ds Front Maverick X3 X rs 156.3 cm (61.5 in) Wheel track Maverick X3 133.1 cm (52.4 in) Maverick X3 X ds Rear Maverick X3 X rs 153.4 cm (60.4 in) Maverick X3 35.6 cm (14 in)
  • Page 122 SPECIFICATIONS This page is intentionally blank ______________...

  • Page 123: Troubleshooting

    TROUBLESHOOTING ______________...

  • Page 124: Troubleshooting Guidelines

    – Check charging system fuse. – Check fault message in cluster. – Check battery connections and terminals condition. – Have the battery checked by an authorized Can-Am dealer. 5. Defective engine start button. – Contact an authorized Can-Am dealer. 6. Defective starter solenoid.
  • Page 125 • Crank engine several times. • Install new spark plugs if possible or clean and dry spark plugs. • If engine does not start, seek service from an authorized Can-Am dealer, repair shop, or person of your own choosing for maintenance, repair, or re- placement.
  • Page 126 6. Lack of fuel – Dirty or clogged fuel pump pre-filter. Seek service from an authorized Can-Am dealer, repair shop, or person of your own choosing for mainte- nance, repair, or replacement. Please refer to the US EPA EMISSIONS-RE- LATED WARRANTY contained herein for information about warranty claims.
  • Page 127 – Use the override switch to retrieve accelerator pedal normal operation. Con- tact an authorized Can-Am dealer. 2. Total failure of the accelerator pedal sensors (PPS). – Use the override switch to bypass the accelerator pedal in order to move ve- hicle. Contact an authorized Can-Am dealer. ______________...

  • Page 128: Messages In Multifunction Gauge

    Check engine pilot light on. Indicates that the DPS (Dynamic CHECK DPS Power Steering) does not work properly. See an authorized Can-Am dealer. When one or both sensor of the PPS is/are faulty, erratic or out of PPS FAULT range or that the ratio between the two is incorrect, the message will be displayed and the check engine will be lit.

  • Page 129: Warranty

    WARRANTY ______________...

  • Page 130: Brp Limited Warranty Usa And Canada: 2017 Can-Am Ssv

    1) SCOPE OF THE LIMITED WARRANTY Bombardier Recreational Products Inc. (“BRP”)* warrants its 2017 Can-Am side-by-side vehicles (“SSV”) sold by authorized Can-Am SSV dealers (as here- inafter defined) in the United States of America (“USA”) and in Canada from defects in material or workmanship for the period and under the conditions de- scribed below.
  • Page 131 This warranty coverage is available only if each of the following conditions has been fulfilled: – The 2017 Can-Am SSV must be purchased as new and unused by its first owner from a Can-Am SSV dealer authorized to distribute Can-Am SSV's in the country in which the sale occurred (“Can-Am SSV dealer”);...
  • Page 132 BRP’s obligations under this warranty are limited to, at its sole discretion, repairing parts found defective under normal use, maintenance and service, or replacing such parts with new genuine Can-Am SSV parts without charge for parts and labor, at any authorized BRP dealer during the warranty coverage period under the conditions described herein.

  • Page 133: Us Epa Emission-Related Warranty

    BRP. For all emission-related warranty claims, BRP is limiting the diagnosis and repair of emission-related parts to the authorized Can-Am dealers, unless for emergency re- pairs as required by item 2 of the following list.
  • Page 134 Components Covered The emission-related warranty covers all components whose failure would in- crease an engine’s emissions of any regulated pollutant, including the following listed components: 1. For exhaust emissions, emission-related components include any engine parts related to the following systems: –...
  • Page 135 Limited Applicability As a certifying manufacturer, BRP may deny emission-related warranty claims for failures that have been caused by the owner’s or operator’s improper main- tenance or use, by accidents for which the manufacturer has no responsibility, or by acts of God. For example, an emission-related warranty claim need not be honored for failures that have been directly caused by the operator’s abuse of the engine/equipment or the operator’s use of the engine/equipment in a manner for which it was not designed and are not attributable to the manufacturer in any way.

  • Page 136: Brp International Limited Warranty: 2017 Can-Am Ssv

    1) SCOPE OF THE LIMITED WARRANTY Bombardier Recreational Products Inc. (“BRP”)* warrants its 2017 Can-Am SSV sold by Can-Am SSV distributors or dealers authorized by BRP to distribute Can-Am SSVs ("Can-Am SSV Distributor/Dealer") outside of the fifty United States, Canada, member states of the European Economic Area (which is comprised of the states of the European Union plus Norway, Iceland and Liechtenstein) (“EEA”), member states of the Commonwealth of the Independent States (in-...
  • Page 137 This warranty coverage is available only if each of the following conditions has been fulfilled: – The 2017 Can-Am SSV must be purchased as new and unused by its first owner from a Can-Am SSV Distributor/Dealer authorized to distribute Can-Am SSVs in the country in which the sale occurred;...
  • Page 138 BRP's responsibility is limited to making the required repairs or replacements of parts. No claim of breach of warranty shall be cause for cancellation or rescission of the sale of the Can-Am SSV to the owner. You may have other legal rights which may vary from country to country.
  • Page 139 9) CONSUMER ASSISTANCE In the event of a controversy or a dispute in connection with this limited warranty, BRP suggests that you try to resolve the issue at the Can-Am SSV Distribu- tor/Dealer level. We recommend discussing the issue with the authorized Can-Am SSV Distributor/Dealer's service manager or owner.

  • Page 140: Brp Limited Warranty For The European Economic Area, The Commonwealth Of The Independant States And Turkey: 2017 Can-Am Ssv

    1) SCOPE OF THE LIMITED WARRANTY Bombardier Recreational Products Inc. (“BRP”)* warrants its 2017 Can-Am SSVs sold by Can-Am SSV distributors or dealers authorized by BRP to distribute Can-Am SSVs (“Can-Am SSV Distributor/Dealer”).in member states of the Euro- pean Economic Area (which is comprised of the member states of the European Union plus Norway, Iceland and Liechtenstein) (“EEA”), in member states of the...
  • Page 141 This warranty coverage is available only if each of the following conditions has been fulfilled: – The 2017 Can-Am SSV must be purchased as new and unused by its first owner from a Can-Am SSV Distributor/Dealer authorized to distribute Can-Am SSVs in the country in which the sale occurred;...
  • Page 142 BRP's responsibility is limited to making the required repairs or replacements of parts. No claim of breach of warranty shall be cause for cancellation or rescission of the sale of the Can-Am SSV to the owner. You may have other legal rights which may vary from country to country.
  • Page 143 9) CONSUMER ASSISTANCE In the event of a controversy or a dispute in connection with this limited warranty, BRP suggests that you try to resolve the issue at the Can-Am SSV Distribu- tor/Dealer level. We recommend discussing the issue with the authorized Can-Am SSV Distributor/Dealer's service manager or owner.
  • Page 144 ADDITIONAL TERMS AND CONDITIONS FOR FRANCE ONLY The following terms and conditions are applicable to products sold in France only: The seller shall deliver goods that are complying with the contract and shall be responsible for defects existing upon delivery. The seller shall also be responsible for defects resulting from packaging, assembling instructions or the installation when it is its responsibility per the contract or if accomplished under its responsibility.

  • Page 145: Customer Information

    CUSTOMER INFORMATION ______________...

  • Page 146: Privacy Information

    PRIVACY INFORMATION BRP wishes to inform you that your coordinates will be used for safety and war- ranty related purposes. Furthermore, BRP and its affiliates may use its customer list to distribute marketing and promotional information about BRP and related products.

  • Page 147: Contact Us

    CONTACT US South America www.brp.com Rua James Clerck Maxwell, 230 North America TechnoPark Campinas SP 13069-380 Brazil 565 de la Montagne Street Valcourt (Québec) J0E 2L0 Asia Canada Sturtevant, Wisconsin, U.S.A. 15/F Parale Mitsui Building,8 10101 Science Drive Higashida-Cho, Kawasaki-ku Sturtevant, Wisconsin Kawasaki 210-0005 53177...

  • Page 148: Change Of Address/Ownership

    It is the owner’s responsibility to notify BRP. STOLEN UNITS: If your personal vehicle is stolen, you should notify BRP or an authorized Can-Am dealer. We will ask you to provide your name, address, phone number, the vehicle identification number and the date it was stolen.
  • Page 149 CHANGE OF ADDRESS/OWNERSHIP ______________...
  • Page 150 CHANGE OF ADDRESS/OWNERSHIP This page is intentionally blank ______________...
  • Page 151 CHANGE OF ADDRESS/OWNERSHIP ______________...
  • Page 152 CHANGE OF ADDRESS/OWNERSHIP This page is intentionally blank ______________...
  • Page 153 CHANGE OF ADDRESS/OWNERSHIP NOTES ______________...
  • Page 154 CHANGE OF ADDRESS/OWNERSHIP NOTES ______________...
  • Page 155 WARNING To reduce risk of serious injury or death, read this Operator’s Guide and safety labels, watch the safety video and: Be prepared • Fasten seat belts and make sure nets and doors are securely latched in place. • Wear an approved helmet and protective gear. •...

Table of Contents
