FUNKY CUB 10cc-15cc
Instruction Manual.
.
M4x20mm
Blind nut.
4) Attach the motor to the front of the
electric motor box using four 4mm blind
nut, four M3x15mm hex head bolts to se-
cure the motor. Please see picture shown.
M3x12mm
Epoxy
4 mm
145 mm
Balsa stick.
4 mm
Epoxy
14
14
