NetComm NF13ACV User Manual page 23

OPTION
DHCP start range
DHCP end range
DHCP lease time (seconds)
Default domain name suffix
DNS server 1 IP address
DNS server 2 IP address
WINS server 1 IP address
WINS server 2 IP address
TFTP Server (Option 66)
Enter the desired DHCP options and click the Save button.
Address reservation list
DHCP clients are dynamically assigned an IP address as they connect, but you can reserve an address for a particular device using
the address reservation list.
To add a device to the address reservation list:
Click the +Add button.
In the MAC address field, enter the device's MAC address.
In the IP address fields, enter the IP address that you wish to reserve for the device.
If the Enable toggle key is not set to ON, click it to switch it to the ON position.
Click the Save button to save the settings.
Dynamic DHCP client list
The Dynamic DHCP client list displays a list of the DHCP clients. If you want to reserve the current IP address for future use, click
the Clone button and the details will be copied to the address reservation list fields. Remember to click the Save button under the
Address reservation list section to confirm the configuration.
www.netcommwireless.com
UM-00013 v1.0
Sets the first IP address of the DHCP range
Sets the last IP address of the DHCP range
The length of time in seconds that DHCP lease allocated is valid
Specifies the default domain name suffix for the DHCP clients. A domain name suffix enables users
to access a local server, for example, server1, without typing the full domain name
server1.domain.com
Specifies the primary DNS (Domain Name System) server's IP address.
Specifies the secondary DNS (Domain Name System) server's IP address.
Specifies the primary WINS (Windows Internet Name Service) server IP address
Specifies the secondary WINS (Windows Internet Name Service) server IP address
Specifies the TFTP (Trivial File Transfer Protocol) server
Table 8 - DHCP configuration
Figure 12 – DHCP – Address reservation list
Figure 13 - Dynamic DHCP client list
DESCRIPTION
NetComm Wireless AC1200 WiFi Gigabit Router with Voice
23
