NetComm NF18ACV Connection Manual

nbn™ Connection Guide - Fixed Wireless (FW)
STEP 1 - Locate the nbn™ Fixed Wireless Network
Termination Device (WNTD)
Find the indoor nbn™ Fixed Wireless Network
Termination Device (WNTD) in your home. This will
usually be installed in a garage or main living area, but
may be located in an odd location such as a wardrobe,
cupboard or underneath a staircase. Ensure you check
your entire home for the WNTD including any unusual
places that you may not expect.
STEP 2 - Connect your modem/router
You will need to plug your modem/router into your
nbn™ Fixed Wireless Network Termination Device
(WNTD) to connect your Internet service.
First, ensure that the included power cable from the
power port on the back of the Fixed Wireless Network
Termination Device (WNTD) is plugged in and secure.
Plug the other end of the power cable into a power
wall outlet in your home and switch the power point
on.
www.barefoottelecom.com.au 1300 017 622 support@barefoottelecom.com.au
After a few minutes, you should notice the POWER,
STATUS and ODU lights on the front of the WNTD
turn solid green. You should also then have at least
one SIGNAL STRENGTH light on (this will usually be
flashing). If the STATUS or ODU lights on your nbn™
Fixed Wireless WNTD remain red or are off, please
contact our support team for further troubleshooting.
Now, take your modem/router's power supply cable
and use it to connect your modem/router's power port
to an electrical outlet. Switch the power point on.
Take your Ethernet cable (this is typically blue, yellow,
grey or white) and plug one end into the required
yellow port marked UNI-D on the back of the nbn™
Fixed Wireless Network Termination Device (WNTD).
The active UNI-D port would have been sent to you via
email and SMS - in many cases this is usually UNI-D1
but may be another number.
Plug the other end of this Ethernet cable into the
WAN port on your modem/router. This may also be
labelled as INTERNET or WAN/LAN. The Ethernet
cable is larger than a telephone cable. DO NOT use
the telephone cable to plug in your modem/router to
the nbn™ Fixed Wireless Network Termination Device
(WNTD).
