XBox Setup Overview
There are two ways of allowing your XBox to communicate with the internet. One is through port forwarding and
the other is through the DMZ feature.
Port forwarding will enable specified ports on the NL1901ACV to get access to your XBox to communicate with the
internet as if they were directly connected by allowing access through.
Setting your XBox as a DMZ host opens all the ports on the NL1901ACV to allow access to a designated device.
This guide has been revised to include the latest changes and updates from the NL1901ACV's new NC2 web user
interface.
Prerequisite
Before you configure the NL1901ACV, you will need to set a static IP address on your XBox.
Please follow the instructions at the link below to set a static IP address on your XBox:
https://portforward.com/networking/static-ip-XBox-one/
You can use an IP address like 192.168.20.100 for example.
Important information
•
You can only forward a port to one location (IP address).
•
In some cases, this may cause issues when multiple LAN devices (computers, game consoles, or VOIP ATAs) attempt to use
online gaming at same time or make multiple VOIP service connections.
•
In these cases, you would need to use an alternate port for any subsequent connections after the first device.
•
Please consult your VOIP provider or game manufacturer for assistance with this.
NF1901ACV FAQs – XBox Setup Guide
FQ01128 v. 1.1 March 2019
XBox Setup Guide
NF1901ACV FAQs
© NetComm Wireless 2019
1 of 7
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for NetComm XBox NF1901ACV
Summary of Contents for NetComm XBox NF1901ACV
- Page 1 In these cases, you would need to use an alternate port for any subsequent connections after the first device. • Please consult your VOIP provider or game manufacturer for assistance with this. NF1901ACV FAQs – XBox Setup Guide 1 of 7 FQ01128 v. 1.1 March 2019 © NetComm Wireless 2019...
- Page 2 Note – If no authentication prompt is displayed or you see a request time out message, refer to the What if I cannot access Web User Interface guide from FAQs section. NF1901ACV FAQs – XBox Setup Guide 2 of 7 FQ01128 v. 1.1 March 2019 © NetComm Wireless 2019...
- Page 3 Click on the Save/Apply button Reboot the modem: Click Management menu on the left-hand side of the page then click Reboot options: Click the Reboot button. NF1901ACV FAQs – XBox Setup Guide 3 of 7 FQ01128 v. 1.1 March 2019 © NetComm Wireless 2019...
- Page 4 It is recommended to change the webpage port number to 8000 as described below. (Remember that from now onwards you can only access the webpage with port 8000.) NF1901ACV FAQs – XBox Setup Guide 4 of 7 FQ01128 v. 1.1 March 2019 © NetComm Wireless 2019...
- Page 5 This example uses Gaming Console . Enter the IP address of the XBox that you wish to port forward to in the Server IP Address field. NF1901ACV FAQs – XBox Setup Guide 5 of 7 FQ01128 v. 1.1 March 2019 © NetComm Wireless 2019...
- Page 6 P O R T N U M B E R TCP and UDP TCP and UDP 3074 3544 4500 Click the Apply/Save button. NF1901ACV FAQs – XBox Setup Guide 6 of 7 FQ01128 v. 1.1 March 2019 © NetComm Wireless 2019...
- Page 7 In these cases, you would need to use an alternate port for any subsequent connections after the first device. • Please consult your VOIP provider or game manufacturer for assistance with this. NF1901ACV FAQs – XBox Setup Guide 7 of 7 FQ01128 v. 1.1 March 2019 © NetComm Wireless 2019...
