NLS-HR200C
Corded 2D Barcode Scanner
User Guide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NLS-HR200C and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Newland NLS-HR200C

Summary of Contents for Newland NLS-HR200C

  • Page 1 NLS-HR200C Corded 2D Barcode Scanner User Guide...
  • Page 2 Do not disassemble the device or remove the seal label from the device. Otherwise, Fujian Newland Auto-ID Tech. Co., Ltd. does not assume responsibility for the warranty or replacement.

  • Page 3: Revision History

    Revision History Version Description Date V1.0.0 Initial release. June 7, 2013...

  • Page 4: Table Of Contents

    Table of Contents Revision History ............................. - 3 -  Preface ................................11  Introduction ............................11  Chapter Description ..........................11  Explanation of Icons ..........................12  Chapter 1 Getting Started ..........................13  Introduction ............................13  Features of the HR200C ........................13  Unpacking .............................. 13  HR200C Corded Scanner ........................
  • Page 5 Aiming ..............................28  Beep ............................... 29  Good Read Beep (Non-Programming Barcode) ................29  Good Read Beep Type ......................29  Good Read Beep Volume ......................30  Good Read Beep (Programming Barcode) ..................30  Startup Beep ............................ 30  Good Read LED Notification ......................... 31  Transmit NGR Message ........................
  • Page 6 USB Enumeration ..........................47  USB HID-KBW ............................48  USB Country Keyboard Types ......................49  Beep on Unknown Character ......................50  Inter-Keystroke Delay ........................51  Convert Case ........................... 52  USB COM Port Emulation ........................53  Chapter 6 Symbologies ........................... 54  Introduction ............................54  General Settings ............................
  • Page 7 Restore Factory Defaults ......................... 65  Enable/Disable UPC-E ........................65  Transmit Check Digit ........................65  Add-On Code ........................... 66  Add-On Code Required ........................67  Transmit System Character “0” ....................... 67  UPC-E Extension ..........................68  UPC-A ..............................69  Restore Factory Defaults ......................... 69  Enable/Disable UPC-A ........................
  • Page 8 Set Length Range for Codabar ....................... 85  Parity Check ............................ 86  Start/Stop Character ........................87  Code 93 ..............................88  Restore Factory Defaults ......................... 88  Enable/Disable Code 93 ........................88  Set Length Range for Code 93 ......................89  Parity Check ............................ 90  UCC/EAN-128 ............................
  • Page 9 Industrial 25 ............................105  Restore Factory Defaults ....................... 105  Enable/Disable Industrial 25 ......................105  Set Length Range for Industrial 25 ....................106  Parity Check ..........................107  Standard 25 ............................108  Restore Factory Defaults ....................... 108  Enable/Disable Standard 25 ......................108  Set Length Range for Standard 25 ....................
  • Page 10 Chapter 7 Prefix & Suffix ..........................125  Introduction ............................125  General Settings ..........................126  Enable/Disable All Prefix/Suffix ..................... 126  Prefix Sequences .......................... 126  Custom Prefix ............................127  Enable/Disable Custom Prefix ....................... 127  Set Custom Prefix .......................... 127  AIM ID Prefix ............................128  Code ID Prefix ............................

  • Page 11: Preface

    Preface Introduction This manual provides detailed instructions for setting up and using the corded 2D barcode scanner NLS-HR200C (hereinafter referred to as “HR200C corded scanner” or “the scanner”). Chapter Description  Chapter 1, Getting Started : Gives a general description of HR200C corded scanner including its technical parameters.

  • Page 12: Explanation Of Icons

    Explanation of Icons This icon indicates something relevant to this manual. This icon indicates this information requires extra attention from the reader. This icon indicates handy tips that can help you use or configure the scanner with ease. This icon indicates practical examples that can help you to acquaint yourself with operations.

  • Page 13: Chapter 1 Getting Started

    The HR200C corded scanner reads a 1D or 2D barcode by capturing its image. Adopting the advanced technology independently developed by Newland Auto-ID Tech, it provides users with three scan modes, including Manual Mode, Sense Mode and Continuous Mode, tailored to different scanning needs.

  • Page 14: Hr200C Corded Scanner

    HR200C Corded Scanner Decode LED: Red : Scanner is powered on. Green: Barcode is decoded successfully. Fig. 1-1 Fig. 1-2...

  • Page 15: Connect Hr200C To A Host

    Data port pinout: Signal Type Function No connection No connection Power+ (+5V) RS-232 output RS-232 input nCTS RS-232 flow control nRTS Ground USB signal Connect HR200C to a Host The HR200C corded scanner must be connected to a Host in actual application, such as PC, POS or any intelligent terminal with USB or RS-232 port, via a communication cable, either USB or RS-232 cable.

  • Page 16: Use Usb Cable

    Use USB Cable Fig. 1-3 Connect the HR200C corded scanner to a Host through a USB cable with RJ45 and USB connectors: Plug the RJ45 connector into the data port (see Fig.1-1) on the scanner. Plug the USB connector into the USB port on the Host.

  • Page 17: Use Rs-232 Cable

    Use RS-232 Cable Fig. 1-4 Connect the HR200C corded scanner to a Host through a RS-232 cable with RJ45, RS-232 and power connectors: Plug the RJ45 connector into the data port (see Fig.1-1) on the scanner. Plug the RS-232 connector into the RS-232 port on the Host. Connect the supplied power adaptor to the power connector of the RS-232 cable.

  • Page 18: Remove Communication Cable

    Remove Communication Cable Fig. 1-5 Get an appropriate needle or a straightened paper clip (Fig. 1-5) and then follow the steps below: Disconnect the power adaptor from mains if there is one. Insert the needle into the hole. Pull out the cable slowly from the scanner while pressing the needle in. Remove the needle.

  • Page 19: Maintenance

    Maintenance  The scan window should be kept clean.  Do not scratch the scan window.  Use soft brush to remove the stain from the scan window.  Use the soft cloth to clean the window, such as eyeglass cleaning cloth. ...

  • Page 20: Dimensions

    Dimensions Side View Fig. 1-6 Front View Fig. 1-7...

  • Page 21: Top View

    Top View Fig. 1-8...

  • Page 22: Scanning Instructions

    Scanning Instructions When the scanner is in the Manual scan mode, you can follow the steps below to scan a barcode:  Press and hold the trigger (see Fig.1-1). Then the scanner will project a red aiming beam.  Aim the red beam across the center of barcode, as shown in Fig.1-9. ...

  • Page 23: Chapter 2 Quickset

    Chapter 2 QuickSet QuickSet QuickSet is Windows-based barcode reading software developed by Newland Auto-ID Tech. Users can use it to develop applications, troubleshoot problems and configure scanners.

  • Page 24: Chapter 3 System Settings

    This method is quite similar to the command programming. QuickSet is a software program particularly designed for Newland products. Note: All settings except temporary ones are stored in non-volatile memory of the scanner and will not be lost by removing power from the scanner.

  • Page 25: Programming Barcode/Command/Function

    【Enter Setup】 Programming Barcode/Command/Function The figure above is an example that shows you the programming barcode and command for the Exit Setup function: 1. The Exit Setup barcode 2. The Exit Setup command 3. The function/feature that can be enabled by using the programming barcode or command listed above.
  • Page 26 【Enter Setup】 Programming barcode data (i.e. the characters under programming barcode) can be transmitted to the Host. Scan the appropriate barcode below to enable or disable the transmission of programming barcode data to the Host. **【Do Not Transmit Programming Barcode Data】 【Transmit Programming Barcode Data】...

  • Page 27: Illumination

    【Enter Setup】 Illumination A couple of illumination options are provided to improve the lighting conditions during every image capture:  Normal: Illumination LEDs are turned on only when scanner is reading barcode.  Always ON: Illumination LEDs keep ON after scanner is powered on. ...

  • Page 28: Aiming

    【Enter Setup】 Aiming When scanning/capturing image, the scanner projects an aiming pattern which allows positioning the target barcode within its field of view and thus makes decoding easier.  Normal: The scanner projects an aiming pattern only during barcode scanning/capture. ...

  • Page 29: Beep

    【Enter Setup】 Beep Good Read Beep (Non-Programming Barcode) Scan the appropriate barcode below to enable or disable the emission of beep when a non-programming barcode is decoded. **【Good Read Beep On, Non-Programming Barcode】 【Good Read Beep Off, Non-Programming Barcode】 Good Read Beep Type 【Type 1】...

  • Page 30: Good Read Beep Volume

    【Enter Setup】 Good Read Beep Volume **【Loud】 【Low】 【Medium】 Good Read Beep (Programming Barcode) Scan the appropriate barcode below to enable or disable the emission of beep when a programming barcode is decoded. 【Good Read Beep Off, Programming Barcode】 **【Good Read Beep On, Programming Barcode】 Startup Beep **【Startup Beep On】...

  • Page 31: Good Read Led Notification

    【Enter Setup】 Good Read LED Notification 【Good Read LED Notification Off】 **【Good Read LED Notification On】 **【Exit Setup】...

  • Page 32: Transmit Ngr Message

    【Enter Setup】 Transmit NGR Message Scan a barcode below to select whether or not to transmit a user-defined NGR (Not Good Read) message when a barcode is not decoded. 【Transmit NGR Message】 **【Do Not Transmit NGR Message】 Edit NGR Message To edit an NGR message, scan the Edit NGR Message barcode and the numeric barcodes corresponding to the ASCII values (decimal) of desired characters and then scan the Save barcode.

  • Page 33: Scan Mode

    【Enter Setup】 Scan Mode Manual Mode A trigger pull activates a decode session. The decode session continues until the barcode is decoded or you release the trigger or decode session timeout occurs. **【Manual Mode】 Decode Session Timeout This parameter sets the maximum time decode session continues during a scan attempt. It is programmable in 1ms increments from 0ms to 3,600,000ms.

  • Page 34: Auto Sleep

    【Enter Setup】 Auto Sleep Auto Sleep allows the scanner in the Manual Mode to automatically enter the sleep or low power mode if no operation or communication is performed for a time period (user programmable). When the scanner is in the sleep mode, receiving trigger signal or communication from the Host can awake the scanner. The scanner returns to full operation within 100ms.

  • Page 35: Sense Mode

    【Enter Setup】 Sense Mode The scanner waits for the image stabilization timeout to occur before activating a decode session every time it detects a change in ambient illumination. Decode session continues until the barcode is decoded or the decode session timeout occurs. In the Sense mode, a trigger pull can also activate a decode session.

  • Page 36: Image Stabilization Timeout

    【Enter Setup】 Image Stabilization Timeout The scanner waits for the image stabilization timeout to occur before activating a decode session every time it detects a change in ambient illumination. The image stabilization timeout is programmable in 1ms increments from 0ms to 1,600ms. The default setting is 500ms. 【Image Stabilization Timeout】...

  • Page 37: Timeout Between Decodes (Same Barcode)

    【Enter Setup】 Timeout between Decodes (Same Barcode) Timeout between Decodes (Same Barcode) can avoid undesired rereading of same barcode in a given period of time. To enable/disable the Timeout between Decodes (Same Barcode), scan the appropriate barcode below. Enable Timeout between Decodes: Do not allow the scanner to re-read same barcode before the timeout between decodes (same barcode) occurs.

  • Page 38: Sensitivity

    【Enter Setup】 Sensitivity Sensitivity specifies the degree of acuteness of the scanner’s response to changes in ambient illumination. The higher the sensitivity, the lower requirement in illumination change to trigger the scanner. You can select an appropriate degree of sensitivity that fits the ambient environment. 【Medium Sensitivity】...

  • Page 39: Continuous Mode

    【Enter Setup】 Continuous Mode If the Continuous mode is enabled, the scanner automatically starts one decode session after another. To suspend/resume barcode reading, simply press the trigger. 【Continuous Mode】 Decode Session Timeout This parameter sets the maximum time decode session continues during a scan attempt. It is programmable in 1ms increments from 0ms to 3,600,000ms.

  • Page 40: Timeout Between Decodes

    【Enter Setup】 Timeout between Decodes This parameter sets the timeout between decode sessions. When a decode session ends, next session will not happen until the timeout between decodes occurs. It is programmable in 1ms increments from 0ms to 65,535ms. The default setting is 1,000ms. 【Timeout between Decodes】...

  • Page 41: Factory Defaults

    【Enter Setup】 Factory Defaults Scanning the following barcode can restore the scanner to the factory defaults. You may need to reset all parameters to the factory defaults when:  scanner is not properly configured so that it fails to decode barcodes. ...

  • Page 42: Chapter 4 Rs-232 Interface

    【Enter Setup】 Chapter 4 RS-232 Interface Introduction If the scanner is connected to the RS-232 port of a Host, you need to scan the following barcode to enable serial communication. To ensure smooth communication and accuracy of data, you need to set communication parameters (including baud rate, parity check, data bit and stop bit) to match the host device.

  • Page 43: Baud Rate

    【Enter Setup】 Baud Rate Baud rate is the number of bits of data transmitted per second. Set the baud rate to match the Host requirements. **【Baud Rate 9600】 【Baud Rate 19200】 【Baud Rate 1200】 【Baud Rate 38400】 【Baud Rate 2400】 【Baud Rate 57600】...

  • Page 44: Parity Check

    【Enter Setup】 Parity Check When the number of data bits is set to 7, you can only select either Even Parity or Odd Parity. The None option will be regarded as Even Parity in this case. **【None】 【Odd Parity】 【Even Parity】 Data Bit When the number of data bits is set to 7, you can only select either Even Parity or Odd Parity.

  • Page 45: Stop Bit

    【Enter Setup】 【7 Data Bits/Even Parity】 【7 Data Bits/Odd Parity】 **【8 Data Bits/ No Parity】 【8 Data Bits/Even Parity】 【8 Data Bits/Odd Parity】 Stop Bit **【1 Stop Bit】 【2 Stop Bits】 **【Exit Setup】...

  • Page 46: Hardware Auto Flow Control

    【Enter Setup】 Hardware Auto Flow Control If CTS flow control is enabled, the scanner determines whether to transmit data based on CTS signal level. When CTS signal is at low level which means the serial port’s cache memory of receiving device (such as PC) is full, the scanner stops sending data through serial port until CTS signal is set to high level by receiving device.

  • Page 47: Chapter 5 Usb Interface

    【Enter Setup】 Chapter 5 USB Interface Introduction There are two options for USB connection.  USB HID-KBW: The scanner’s transmission is simulated as USB keyboard input with no need for command configuration or a driver. The barcode data could be entered by the virtual keyboard directly and it is also convenient for the Host to receive data.

  • Page 48: Usb Hid-Kbw

    【Enter Setup】 USB HID-KBW When the scanner is connected to the USB port on a Host, you can enable the USB HID-KBW feature by scanning the barcode below. Then scanner’s transmission will be simulated as USB keyboard input. The Host receives keystrokes on the virtual keyboard. It works on a Plug and Play basis and no driver is required.

  • Page 49: Usb Country Keyboard Types

    【Enter Setup】 USB Country Keyboard Types Keyboard layouts vary from country to country. The default setting is 1-U.S. keyboard. 【2 - Japan】 **【1 - U.S】 【3 - Denmark】 【4 - Finland】 【5 - France】 【6 - Turkey_F】 【7 - Italy】 【8 - Norway】...

  • Page 50: Beep On Unknown Character

    【Enter Setup】 Beep on Unknown Character Due to the differences in keyboard layouts, some characters contained in barcode data may be unavailable on the selected keyboard. As a result, the scanner fails to transmit the unknown characters. Scan the appropriate barcode below to enable or disable the emission of beep when an unknown character is detected.

  • Page 51: Inter-Keystroke Delay

    【Enter Setup】 Inter-Keystroke Delay This parameter specifies the delay between emulated keystrokes. **【No Delay】 【Long Delay (40ms)】 【Short Delay (20ms)】 **【Exit Setup】...

  • Page 52: Convert Case

    【Enter Setup】 Convert Case Scan the appropriate barcode below to convert barcode data to your desired case. **【No Case Conversion】 【Invert Upper and Lower Case Characters】 【Convert All to Upper Case】 【Convert All to Lower Case】 When the Invert Upper and Lower Case Characters feature is enabled, barcode data “AbC”...

  • Page 53: Usb Com Port Emulation

    【Enter Setup】 USB COM Port Emulation If your scanner is connected to the USB port on a Host, the USB COM Port Emulation feature allows the Host to receive data in the way as a serial port does. However, you need to set communication parameters on the scanner to match the Host requirements.

  • Page 54: Chapter 6 Symbologies

    【Enter Setup】 Chapter 6 Symbologies Introduction Every symbology (barcode type) has its own unique attributes. This chapter provides programming barcodes for configuring the scanner so that it can identify various barcode symbologies. The more symbologies you enable, the slower your scanner decodes. It is recommended to disable those that are rarely used to improve the performance of the scanner.

  • Page 55: Enable 1D Symbologies

    【Enter Setup】 Enable 1D Symbologies 【Enable 1D Symbologies】 Disable 1D Symbologies 【Disable 1D Symbologies】 Enable 2D Symbologies 【Enable 2D Symbologies】 Disable 2D Symbologies 【Disable 2D Symbologies】 **【Exit Setup】...

  • Page 56: Video Reverse

    【Enter Setup】 Video Reverse Regular barcode: Dark image on a bright background. Inverse barcode: Bright image on a dark background. The examples of regular barcode and inverse barcode are shown below. Regular Barcode Inverse Barcode Video Reverse is used to allow the scanner to read barcodes that are inverted. Video Reverse ON: Read both regular barcodes and inverse barcodes.

  • Page 57: Code 128

    【Enter Setup】 Code 128 Restore Factory Defaults 【Restore the Factory Defaults of Code 128】 Enable/Disable Code 128 **【Enable Code 128】 【Disable Code 128】 If the scanner fails to identify Code 128 barcodes, you may first try this solution by scanning the Enter Setup barcode and then Enable Code 128 barcode. **【Exit Setup】...

  • Page 58: Set Length Range For Code 128

    【Enter Setup】 Set Length Range for Code 128 The scanner can be configured to only decode Code 128 barcodes with lengths that fall between (inclusive) the minimum and maximum lengths. To accomplish it, you need to set the minimum and maximum lengths.

  • Page 59: Restore Factory Defaults

    【Enter Setup】 EAN-8 Restore Factory Defaults 【Restore the Factory Defaults of EAN-8】 Enable/Disable EAN-8 **【Enable EAN-8】 【Disable EAN-8】 Transmit Check Digit EAN-8 is 8 digits in length with the last one as its check digit used to verify the accuracy of the data. **【Transmit EAN-8 Check Digit】...

  • Page 60: Add-On Code

    【Enter Setup】 Add-On Code An EAN-8 barcode can be augmented with a two-digit or five-digit add-on code to form a new one. In the examples below, the part surrounded by blue dotted line is an EAN-8 barcode while the part circled by red dotted line is add-on code.

  • Page 61: Add-On Code Required

    【Enter Setup】 Add-On Code Required EAN-8 Add-On Code Required: The scanner only decodes EAN-8 barcodes that contain add-on codes. EAN-8 Add-On Code Not Required: The scanner decodes a mix of EAN-8 barcodes with and without add-on codes. 【EAN-8 Add-On Code Required】 **【EAN-8 Add-On Code Not Required】...

  • Page 62: Ean-13

    【Enter Setup】 EAN-13 Restore Factory Defaults **【Restore the Factory Defaults of EAN-13】 Enable/Disable EAN-13 **【Enable EAN-13】 【Disable EAN-13】 Transmit Check Digit **【Transmit EAN-13 Check Digit】 【Do Not Transmit EAN-13 Check Digit】 **【Exit Setup】...

  • Page 63: Add-On Code

    【Enter Setup】 Add-On Code An EAN-13 barcode can be augmented with a two-digit or five-digit add-on code to form a new one. In the examples below, the part surrounded by blue dotted line is an EAN-13 barcode while the part circled by red dotted line is add-on code.

  • Page 64: Add-On Code Required

    【Enter Setup】 Add-On Code Required EAN-13 Add-On Code Required: The scanner only decodes EAN-13 barcodes that contain add-on codes. EAN-13 Add-On Code Not Required: The scanner decodes a mix of EAN-13 barcodes with and without add-on codes. 【EAN-13 Add-On Code Required】 **【EAN-13 Add-On Code Not Required】...

  • Page 65: Upc-E

    【Enter Setup】 UPC-E Restore Factory Defaults **【Restore the Factory Defaults of UPC-E】 Enable/Disable UPC-E **【Enable UPC-E】 【Disable UPC-E】 If the scanner fails to identify UPC-E barcodes, you may first try this solution by scanning the Enter Setup barcode and then Enable UPC-E barcode. Transmit Check Digit UPC-E is 8 digits in length with the last one as its check digit used to verify the accuracy of the data.

  • Page 66: Add-On Code

    【Enter Setup】 Add-On Code A UPC-E barcode can be augmented with a two-digit or five-digit add-on code to form a new one. In the examples below, the part surrounded by blue dotted line is a UPC-E barcode while the part circled by red dotted line is add-on code.

  • Page 67: Add-On Code Required

    【Enter Setup】 Add-On Code Required UPC-E Add-On Code Required: The scanner only decodes UPC-E barcodes that contain add-on codes. UPC-E Add-On Code Not Required: The scanner decodes a mix of UPC-E barcodes with and without add-on codes. 【UPC-E Add-On Code Required】 **【UPC-E Add-On Code Not Required】...

  • Page 68: Upc-E Extension

    【Enter Setup】 UPC-E Extension Disable UPC-E Extend: Transmit UPC-E barcodes as is. Enable UPC-E Extend”: Extend UPC-E barcodes to make them compatible in length to UPC-A. **【Disable UPC-E Extend】 【Enable UPC-E Extend】 **【Exit Setup】...

  • Page 69: Upc-A

    【Enter Setup】 UPC-A Restore Factory Defaults Restore the Factory Defaults of UPC-A】 Enable/Disable UPC-A **【Enable UPC-A】 【Disable UPC-A】 If the scanner fails to identify UPC-A barcodes, you may first try this solution by scanning the Enter Setup barcode and then Enable UPC-A barcode. Transmit Check Digit UPC-A is 12 digits in length with the last one as its check digit used to verify the accuracy of the data.

  • Page 70: Add-On Code

    【Enter Setup】 Add-On Code A UPC-A barcode can be augmented with a two-digit or five-digit add-on code to form a new one. In the examples below, the part surrounded by blue dotted line is a UPC-A barcode while the part circled by red dotted line is add-on code.

  • Page 71: Add-On Code Required

    【Enter Setup】 Add-On Code Required UPC-A Add-On Code Required: The scanner only decodes UPC-A barcodes that contain add-on codes. UPC-A Add-On Code Not Required: The scanner decodes a mix of UPC-A barcodes with and without add-on codes. 【UPC-A Add-On Code Required】 **【UPC-A Add-On Code Not Required】...

  • Page 72: Interleaved 2 Of 5

    【Enter Setup】 Interleaved 2 of 5 Restore Factory Defaults 【Restore the Factory Defaults of Interleaved 2 of 5】 Enable/Disable Interleaved 2 of 5 **【Enable Interleaved 2 of 5】 【Disable Interleaved 2 of 5】 If the scanner fails to identify Interleaved 2 of 5 barcodes, you may first try this solution by scanning the Enter Setup barcode and then Enable Interleaved 2 of 5 barcode.

  • Page 73: Set Length Range For Interleaved 2 Of 5

    【Enter Setup】 Set Length Range for Interleaved 2 of 5 The scanner can be configured to only decode Interleaved 2 of 5 barcodes with lengths that fall between (inclusive) the minimum and maximum lengths. To accomplish it, you need to set the minimum and maximum lengths.

  • Page 74: Parity Check

    【Enter Setup】 Parity Check A check digit is optional for Interleaved 2 o 5 and can be added as the last digit. It is a calculated value used to verify the accuracy of the data. No Parity Check: The scanner transmits Interleaved 2 of 5 barcodes as is. Do Not Transmit Check Digit After Parity Check: The scanner will run a parity check using the last digit of Interleaved 2 of 5 barcode as check digit.

  • Page 75: Itf-14

    【Enter Setup】 ITF-14 ITF-14 is a special kind of Interleaved 2 of 5 with a length of 14 characters and the last character as the check character. 【Restore the Factory Defaults of ITF-14】 **【Disable ITF-14】 【Enable ITF-14 But Do Not Transmit Check Digit】 【Enable ITF-14 and Transmit Check Digit】...

  • Page 76: Itf-6

    【Enter Setup】 ITF-6 ITF-6 is a special kind of Interleaved 2 of 5 with a length of 6 characters and the last character as the check character. 【Restore the Factory Defaults of ITF-6】 **【Disable ITF-6】 【Enable ITF-6 But Do Not Transmit Check Digit】 【Enable ITF-6 and Transmit Check Digit】...

  • Page 77: Matrix 2 Of 5

    【Enter Setup】 Matrix 2 of 5 Restore Factory Defaults 【Restore the Factory Defaults of Matrix 2 of 5】 Enable/Disable Matrix 2 of 5 【Enable Matrix 2 of 5】 **【Disable Matrix 2 of 5】 If the scanner fails to identify Matrix 2 of 5 barcodes, you may first try this solution by scanning the Enter Setup barcode and then Enable Matrix 2 of 5 barcode.

  • Page 78: Set Length Range For Matrix 2 Of 5

    【Enter Setup】 Set Length Range for Matrix 2 of 5 The scanner can be configured to only decode Matrix 2 of 5 barcodes with lengths that fall between (inclusive) the minimum and maximum lengths. To accomplish it, you need to set the minimum and maximum lengths.

  • Page 79: Parity Check

    【Enter Setup】 Parity Check A check digit is optional for Matrix 2 of 5 and can be added as the last digit. It is a calculated value used to verify the accuracy of the data. No Parity Check: The scanner transmits Matrix 2 of 5 barcodes as is. Do Not Transmit Check Digit After Parity Check: The scanner will run a parity check using the last digit of Matrix 2 of 5 barcode as check digit.

  • Page 80: Code 39

    【Enter Setup】 Code 39 Restore Factory Defaults 【Restore the Factory Defaults of Code 39】 Enable/Disable Code 39 **【Enable Code 39】 【Disable Code 39】 If the scanner fails to identify Code 39 barcodes, you may first try this solution by scanning the Enter Setup barcode and then Enable Code 39 barcode. Transmit Start/Stop Character Code 39 uses an asterisk (*) for both the start and the stop characters.

  • Page 81: Set Length Range For Code 39

    【Enter Setup】 Set Length Range for Code 39 The scanner can be configured to only decode Code 39 barcodes with lengths that fall between (inclusive) the minimum and maximum lengths. To accomplish it, you need to set the minimum and maximum lengths.

  • Page 82: Parity Check

    【Enter Setup】 Parity Check A check digit is optional for Code 39 and can be added as the last digit. It is a calculated value used to verify the accuracy of the data. No Parity Check: The scanner transmits Code 39 barcodes as is. Do Not Transmit Check Digit After Parity Check: The scanner will run a parity check using the last digit of Code 39 barcode as check digit.

  • Page 83: Enable/Disable Code 39 Full Ascii

    【Enter Setup】 Enable/Disable Code 39 Full ASCII The scanner can be configured to identify all ASCII characters by scanning the appropriate barcode below. 【Disable Code 39 Full ASCII】 **【Enable Code 39 Full ASCII】 **【Exit Setup】...

  • Page 84: Codabar

    【Enter Setup】 Codabar Restore Factory Defaults 【Restore the Factory Defaults of Codabar】 Enable/Disable Codabar **【Enable Codabar】 【Disable Codabar】 If the scanner fails to identify Codabar barcodes, you may first try this solution by scanning the Enter Setup barcode and then Enable Codabar barcode. **【Exit Setup】...

  • Page 85: Set Length Range For Codabar

    【Enter Setup】 Set Length Range for Codabar The scanner can be configured to only decode Codabar barcodes with lengths that fall between (inclusive) the minimum and maximum lengths. To accomplish it, you need to set the minimum and maximum lengths. 【Set the Minimum Length (Default: 1)】...

  • Page 86: Parity Check

    【Enter Setup】 Parity Check A check digit is optional for Codabar and can be added as the last digit. It is a calculated value used to verify the accuracy of the data. No Parity Check: The scanner transmits Codabar barcodes as is. Do Not Transmit Check Digit After Parity Check: The scanner will run a parity check using the last digit of Codabar barcode as check digit.

  • Page 87: Start/Stop Character

    【Enter Setup】 Start/Stop Character You can set the start/stop characters and choose whether or not to transmit the start/stop characters by scanning the appropriate barcode below. 【Transmit Start/Stop Character】 **【Do Not Transmit Start/Stop Character】 **【ABCD/ABCD as the Start/Stop Character】 【Start/Stop Character in Uppercase】 【ABCD/TN*E as the Start/Stop Character】...

  • Page 88: Code 93

    【Enter Setup】 Code 93 Restore Factory Defaults 【Restore the Factory Defaults of Code 93】 Enable/Disable Code 93 **【Enable Code 93】 【Disable Code 93】 If the scanner fails to identify Code 93 barcodes, you may first try this solution by scanning the Enter Setup barcode and then Enable Code 93 barcode. **【Exit Setup】...

  • Page 89: Set Length Range For Code 93

    【Enter Setup】 Set Length Range for Code 93 The scanner can be configured to only decode Code 93 barcodes with lengths that fall between (inclusive) the minimum and maximum lengths. To accomplish it, you need to set the minimum and maximum lengths.

  • Page 90: Parity Check

    【Enter Setup】 Parity Check Check digits are optional for Code 93 and can be added as the last two digits, which are calculated values used to verify the accuracy of the data. No Parity Check: The scanner transmits Code 93 barcodes as is. Do Not Transmit Check Digit After Parity Check: The scanner will run parity checks using the last two digits of Code 93 barcode as check digits.

  • Page 91: Ucc/Ean-128

    【Enter Setup】 UCC/EAN-128 Restore Factory Defaults 【Restore the Factory Defaults of UCC/EAN-128】 Enable/Disable UCC/EAN-128 **【Enable UCC/EAN-128】 【Disable UCC/EAN-128】 If the scanner fails to identify UCC/EAN-128 barcodes, you may first try this solution by scanning the Enter Setup barcode and then Enable UCC/EAN-128 barcode. **【Exit Setup】...

  • Page 92: Set Length Range For Ucc/Ean-128

    【Enter Setup】 Set Length Range for UCC/EAN-128 The scanner can be configured to only decode UCC/EAN-128 barcodes with lengths that fall between (inclusive) the minimum and maximum lengths. To accomplish it, you need to set the minimum and maximum lengths. 【Set the Minimum Length (Default: 1)】...

  • Page 93: Gs1 Databar

    【Enter Setup】 GS1 Databar Restore Factory Defaults 【Restore the Factory Defaults of GS1 Databar】 Enable/Disable GS1 Databar **【Enable GS1 Databar】 【Disable GS1 Databar】 If the scanner fails to identify GS1 Databar barcodes, you may first try this solution by scanning the Enter Setup barcode and then Enable GS1 Databar barcode. Transmit Application Identifier “01”...

  • Page 94: Code 11

    【Enter Setup】 Code 11 Restore Factory Defaults 【Restore the Factory Defaults of Code 11】 Enable/Disable Code 11 **【Enable Code 11】 【Disable Code 11】 If the scanner fails to identify Code 11 barcodes, you may first try this solution by scanning the Enter Setup barcode and then Enable Code 11 barcode. **【Exit Setup】...

  • Page 95: Set Length Range For Code 11

    【Enter Setup】 Set Length Range for Code 11 The scanner can be configured to only decode Code 11 barcodes with lengths that fall between (inclusive) the minimum and maximum lengths. To accomplish it, you need to set the minimum and maximum lengths.

  • Page 96: Parity Check

    【Enter Setup】 Parity Check Check digits are optional for Code 11 and can be added as the last one or two digits, which are calculated values used to verify the accuracy of the data. If the No Parity Check option is enabled, the scanner transmits Code 11 barcodes as is. 【No Parity Check】...

  • Page 97: Isbn

    【Enter Setup】 ISBN Restore Factory Defaults 【Restore the Factory Defaults of ISBN】 Enable/Disable ISBN 【Enable ISBN】 **【Disable ISBN】 If the scanner fails to identify ISBN barcodes, you may first try this solution by scanning the Enter Setup barcode and then Enable ISBN barcode. Set ISBN Format **【ISBN-13】...

  • Page 98: Add-On Code

    【Enter Setup】 Add-On Code An ISBN barcode can be augmented with a two-digit or five-digit add-on code to form a new one. 【Enable 2-Digit Add-On Code】 **【Disable 2-Digit Add-On Code】 【Enable 5-Digit Add-On Code】 **【Disable 5-Digit Add-On Code】 Enable 2-Digit Add-On Code/ Enable 5-Digit Add-On Code: The scanner decodes a mix of ISBN barcodes with and without 2-digit/5-digit add-on codes.

  • Page 99: Add-On Code Required

    【Enter Setup】 Add-On Code Required ISBN Add-On Code Required: The scanner only decodes ISBN barcodes that contain add-on codes. ISBN Add-On Code Not Required: The scanner decodes a mix of ISBN barcodes with and without add-on codes. 【ISBN Add-On Code Required】 **【ISBN Add-On Code Not Required】...

  • Page 100: Issn

    【Enter Setup】 ISSN Restore Factory Defaults 【Restore the Factory Defaults of ISSN】 Enable/Disable ISSN 【Enable ISSN】 **【Disable ISSN】 If the scanner fails to identify ISSN barcodes, you may first try this solution by scanning the Enter Setup barcode and then Enable ISSN barcode. **【Exit Setup】...

  • Page 101: Add-On Code

    【Enter Setup】 Add-On Code An ISSN barcode can be augmented with a two-digit or five-digit add-on code to form a new one. 【Enable 2-Digit Add-On Code】 **【Disable 2-Digit Add-On Code】 【Enable 5-Digit Add-On Code】 **【Disable 5-Digit Add-On Code】 Enable 2-Digit Add-On Code/ Enable 5-Digit Add-On Code: The scanner decodes a mix of ISSN barcodes with and without 2-digit/5-digit add-on codes.

  • Page 102: Add-On Code Required

    【Enter Setup】 Add-On Code Required ISSN Add-On Code Required: The scanner only decodes ISSN barcodes that contain add-on codes. ISSN Add-On Code Not Required: The scanner decodes a mix of ISSN barcodes with and without add-on codes. 【ISSN Add-On Code Required】 **【ISSN Add-On Code Not Required】...

  • Page 103: Aim-128

    【Enter Setup】 AIM-128 Restore Factory Defaults 【Restore the Factory Defaults of AIM-128】 Enable/Disable AIM-128 【Disable AIM-128】 **【Enable AIM-128】 If the scanner fails to identify AIM-128 barcodes, you may first try this solution by scanning the Enter Setup barcode and then Enable AIM-128 barcode. **【Exit Setup】...

  • Page 104: Set Length Range For Aim-128

    【Enter Setup】 Set Length Range for AIM-128 The scanner can be configured to only decode AIM-128 barcodes with lengths that fall between (inclusive) the minimum and maximum lengths. To accomplish it, you need to set the minimum and maximum lengths. 【Set the Minimum Length (Default: 1)】...

  • Page 105: Industrial 25

    【Enter Setup】 Industrial 25 Restore Factory Defaults 【Restore the Factory Defaults of Industrial 25】 Enable/Disable Industrial 25 **【Enable Industrial 25】 【Disable Industrial 25】 If the scanner fails to identify Industrial 25 barcodes, you may first try this solution by scanning the Enter Setup barcode and then Enable Industrial 25 barcode. **【Exit Setup】...

  • Page 106: Set Length Range For Industrial 25

    【Enter Setup】 Set Length Range for Industrial 25 The scanner can be configured to only decode Industrial 25 barcodes with lengths that fall between (inclusive) the minimum and maximum lengths. To accomplish it, you need to set the minimum and maximum lengths.

  • Page 107: Parity Check

    【Enter Setup】 Parity Check A check digit is optional for Industrial 25 and can be added as the last digit. It is a calculated value used to verify the accuracy of the data. No Parity Check: The scanner transmits Industrial 25 barcodes as is. Do Not Transmit Check Digit After Parity Check: The scanner will run a parity check using the last digit of Industrial 25 barcode as check digit.

  • Page 108: Standard 25

    【Enter Setup】 Standard 25 Restore Factory Defaults 【Restore the Factory Defaults of Standard 25】 Enable/Disable Standard 25 **【Enable Standard 25】 【Disable Standard 25】 If the scanner fails to identify Standard 25 barcodes, you may first try this solution by scanning the Enter Setup barcode and then Enable Standard 25 barcode. **【Exit Setup】...

  • Page 109: Set Length Range For Standard 25

    【Enter Setup】 Set Length Range for Standard 25 The scanner can be configured to only decode Standard 25 barcodes with lengths that fall between (inclusive) the minimum and maximum lengths. To accomplish it, you need to set the minimum and maximum lengths.

  • Page 110: Parity Check

    【Enter Setup】 Parity Check A check digit is optional for Standard 25 and can be added as the last digit. It is a calculated value used to verify the accuracy of the data. No Parity Check: The scanner transmits Standard 25 barcodes as is. Do Not Transmit Check Digit After Parity Check: The scanner will run a parity check using the last digit of Standard 25 barcode as check digit.

  • Page 111: Plessey

    【Enter Setup】 Plessey Restore Factory Defaults 【Restore the Factory Defaults of Plessey】 Enable/Disable Plessey 【Enable Plessey】 **【Disable Plessey】 If the scanner fails to identify Plessey barcodes, you may first try this solution by scanning the Enter Setup barcode and then Enable Plessey barcode. **【Exit Setup】...

  • Page 112: Set Length Range For Plessey

    【Enter Setup】 Set Length Range for Plessey The scanner can be configured to only decode Plessey barcodes with lengths that fall between (inclusive) the minimum and maximum lengths. To accomplish it, you need to set the minimum and maximum lengths. 【Set the Minimum Length (Default: 1)】...

  • Page 113: Parity Check

    【Enter Setup】 Parity Check Check digits are optional for Plessey and can be added as the last two digits, which are calculated values used to verify the accuracy of the data. No Parity Check: The scanner transmits Plessey barcodes as is. Do Not Transmit Check Digit After Parity Check: The scanner will run parity checks using the last two digits of Plessey barcode as check digits.

  • Page 114: Msi-Plessey

    【Enter Setup】 MSI-Plessey Restore Factory Defaults 【Restore the Factory Defaults of MSI-Plessey】 Enable/Disable MSI-Plessey 【Enable MSI-Plessey】 **【Disable MSI-Plessey】 If the scanner fails to identify MSI-Plessey barcodes, you may first try this solution by scanning the Enter Setup barcode and then Enable MSI-Plessey barcode. **【Exit Setup】...

  • Page 115: Set Length Range For Msi-Plessey

    【Enter Setup】 Set Length Range for MSI-Plessey The scanner can be configured to only decode MSI-Plessey barcodes with lengths that fall between (inclusive) the minimum and maximum lengths. To accomplish it, you need to set the minimum and maximum lengths. 【Set the Minimum Length (Default: 2)】...

  • Page 116: Parity Check

    【Enter Setup】 Parity Check Check digits are optional for MSI-Plessey and can be added as the last one or two digits, which are calculated values used to verify the accuracy of the data. If the No Parity Check option is enabled, the scanner transmits MSI-Plessey barcodes as is. 【No Parity Check】...

  • Page 117: Pdf417

    【Enter Setup】 PDF417 Restore Factory Defaults **【Restore the Factory Defaults of PDF417】 Enable/Disable PDF417 **【Enable PDF417】 【Disable PDF417】 If the scanner fails to identify PDF417 barcodes, you may first try this solution by scanning the Enter Setup barcode and then Enable PDF417 barcode. **【Exit Setup】...

  • Page 118: Set Length Range For Pdf417

    【Enter Setup】 Set Length Range for PDF417 The scanner can be configured to only decode PDF417 barcodes with lengths that fall between (inclusive) the minimum and maximum lengths. To accomplish it, you need to set the minimum and maximum lengths. 【Set the Minimum Length (Default: 1)】...

  • Page 119: Qr Code

    【Enter Setup】 QR Code Restore Factory Defaults 【Restore the Factory Defaults of QR Code】 Enable/Disable QR Code **【Enable QR Code】 【Disable QR Code】 If the scanner fails to identify QR Code barcodes, you may first try this solution by scanning the Enter Setup barcode and then Enable QR Code barcode. **【Exit Setup】...

  • Page 120: Set Length Range For Qr Code

    【Enter Setup】 Set Length Range for QR Code The scanner can be configured to only decode QR Code barcodes with lengths that fall between (inclusive) the minimum and maximum lengths. To accomplish it, you need to set the minimum and maximum lengths.

  • Page 121: Micro Qr

    【Enter Setup】 Micro QR 【Disable Micro QR】 **【Enable Micro QR】 **【Exit Setup】...

  • Page 122: Data Matrix

    【Enter Setup】 Data Matrix Restore Factory Defaults 【Restore the Factory Defaults of Data Matrix】 Enable/Disable Data Matrix **【Enable Data Matrix】 【Disable Data Matrix】 If the scanner fails to identify Data Matrix barcodes, you may first try this solution by scanning the Enter Setup barcode and then Enable Data Matrix barcode. **【Exit Setup】...

  • Page 123: Set Length Range For Data Matrix

    【Enter Setup】 Set Length Range for Data Matrix The scanner can be configured to only decode Data Matrix barcodes with lengths that fall between (inclusive) the minimum and maximum lengths. To accomplish it, you need to set the minimum and maximum lengths.

  • Page 124: Rectangular Barcode

    【Enter Setup】 Rectangular Barcode Data Matrix has two formats: Square barcodes having the same amount of modules in length and width: 10*10, 12*12..144*144. Rectangular barcodes having different amounts of models in length and width: 6*16, 6*14... 14*22. **【Enable Rectangular Barcode】 【Disable Rectangular Barcode】...

  • Page 125: Chapter 7 Prefix & Suffix

    【Enter Setup】 Chapter 7 Prefix & Suffix Introduction A 1D barcode could contain digits, letters, symbols, etc. A 2D barcode could contain more data, such as Chinese characters and other multi-byte characters. However, in real applications, they do not and should not have all information we need, such as barcode type, data acquisition time and delimiter, in order to keep the barcodes short and flexible.

  • Page 126: General Settings

    【Enter Setup】 General Settings Enable/Disable All Prefix/Suffix Disable All Prefix/Suffix: Transmit barcode data with no prefix/suffix. Enable All Prefix/Suffix: Allow user to append Code ID prefix, AIM ID prefix, custom prefix/suffix and terminating character to the barcode data before the transmission. 【Disable All Prefix/Suffix】...

  • Page 127: Custom Prefix

    【Enter Setup】 Custom Prefix Enable/Disable Custom Prefix If custom prefix is enabled, you are allowed to append to the data a user-defined prefix that cannot exceed 10 characters. For example, if the custom prefix is “AB” and the barcode data is “123”, the Host will receive “AB123”.

  • Page 128: Aim Id Prefix

    【Enter Setup】 AIM ID Prefix AIM (Automatic Identification Manufacturers) ID defines symbology identifier (For the details, see the “Appendix 2: AIM ID Table” section). If AIM ID prefix is enabled, the scanner will add the symbology identifier before the scanned data after decoding. **【Disable AIM ID Prefix】...

  • Page 129: Restore All Default Code Ids

    【Enter Setup】 Restore All Default Code IDs For the information of default Code IDs, see the “Code ID Table” section in Appendix. 【Restore All Default Code IDs】 Modify Code ID See the examples below to learn how to modify a Code ID and restore the default Code IDs of all symbologies.
  • Page 130 【Enter Setup】 【Modify PDF417 Code ID】 【Modify Data Matrix Code ID】 【Modify QR Code ID】 【Modify Matrix 25 Code ID】 【Modify ISSN Code ID】 【Modify AIM-128 Code ID】 【Modify EAN-8 Code ID】 【Modify ITF-6 Code ID】 **【Exit Setup】...
  • Page 131 【Enter Setup】 【Modify EAN-13 Code ID】 【Modify Code 39 Code ID】 【Modify UPC-E Code ID】 【Modify Codabar Code ID】 【Modify UPC-A Code ID】 【Modify Code 93 Code ID】 【Modify Interleaved 2 of 5 Code ID】 【Modify Code 128 Code ID】 **【Exit Setup】...
  • Page 132 【Enter Setup】 【Modify ITF-14 Code ID】 【Modify ISBN Code ID】 【Modify UCC/EAN-128 Code ID】 【Modify Industrial 25 Code ID】 【Modify Code 11 Code ID】 【Modify Standard 25 Code ID】 【Modify Plessey Code ID】 【Modify MSI-Plessey Code ID】 【Modify GS1 Databar Code ID】 **【Exit Setup】...

  • Page 133: Custom Suffix

    【Enter Setup】 Custom Suffix Enable/Disable Custom Suffix If custom suffix is enabled, you are allowed to append to the data a user-defined suffix that cannot exceed 10 characters. For example, if the custom suffix is “AB” and the barcode data is “123”, the Host will receive “123AB”.

  • Page 134: Terminating Character Suffix

    【Enter Setup】 Terminating Character Suffix Enable/Disable Terminating Character Suffix A terminating character such as carriage return (CR) or carriage return/line feed pair (CRLF) can only be used to mark the end of data, which means nothing can be added after it. 【Disable Terminating Character Suffix】...
  • Page 135 【Enter Setup】 To set a terminating character suffix, scan the Set Terminating Character Suffix barcode and the numeric barcodes representing the hexadecimal value of a desired terminating character and then scan the Save barcode. Refer to Appendix 4: ASCII Table for hexadecimal values of terminating characters. Note: A terminating character suffix cannot exceed 2 characters.

  • Page 136: Chapter 8 Ambient Illumination

    【Enter Setup】 Chapter 8 Ambient Illumination Ambient lighting conditions may vary from one operating environment to another, such as fluorescent lit warehouses or sunlit open spaces. Fluorescent lights may flicker when using AC power source in 50-60Hz. Usually indoor illuminance is around 1,000 lux while outdoor illuminance may reach 60,000 lux or even over 100,000 lux.

  • Page 137: Appendix

    Appendix Digit Barcodes After scanning numeric barcode(s), you need to scan the Save barcode to save the data. 【0】 【1】 【2】 【3】 【4】 【5】...
  • Page 138 【6】 【7】 【8】 【9】...
  • Page 139 【A】 【B】 【C】 【D】 【E】 【F】...

  • Page 140: Save/Cancel Barcodes

    Save/Cancel Barcodes After reading numeric barcode(s), you need to scan the Save barcode to save the data. If you scan the wrong digit(s), you can either scan the Cancel barcode and then start the configuration all over again, or scan the Delete the Last Digit barcode and then the correct digit, or scan the Delete All Digits barcode and then the digits you want.

  • Page 141: Factory Defaults Table

    Factory Defaults Table Parameter Factory Default Remark Programming Barcode Disabled Barcode Programming Do not send Programming Barcode Data Communication Settings Interface USB HID-KBW 9600 Baud Rate None Parity Check TTL-232 Data Bit Stop Bit No flow control Hardware Flow Control U.S.
  • Page 142 Parameter Factory Default Remark Applicable to all three scan Decode Session Timeout 3,000ms modes. Continuous Mode 0~3,600,000ms Timeout between Decodes 1,000ms 0~65,535ms Illumination & Aiming Illumination Normal Aiming Normal Notifications Startup Beep Enabled Notification Enabled Good Read Beep (Non-Programming Beep Type Type 3 Barcode) Beep Volume...
  • Page 143 Parameter Factory Default Remark Symbologies Applicable to all Video Reverse Disabled symbologies. Code 128 Code 128 Enabled Maximum Length Minimum Length UCC/EAN-128 UCC/EAN-128 Enabled Maximum Length Minimum Length AIM-128 AIM-128 Enabled Maximum Length Minimum Length EAN-8 EAN-8 Enabled Check Digit Transmit 2-Digit Add-On Code Disabled...
  • Page 144 Parameter Factory Default Remark ISBN ISBN Disabled ISBN Format ISBN-13 2-Digit Add-On Code Disabled 5-Digit Add-On Code Disabled Add-On Code Not required UPC-E UPC-E Enabled Check Digit Transmit 2-Digit Add-On Code Disabled 5-Digit Add-On Code Disabled Add-On Code Not required Extend to UPC-A Disabled System Character “0”...
  • Page 145 Parameter Factory Default Remark ITF-14 ITF-14 Disabled Do not transmit Check Digit Matrix 2 of 5 Matrix 2 of 5 Disabled Parity Check Enabled Check Digit Do not transmit Maximum Length Minimum Length Industrial 2 of 5 Industrial 2 of 5 Enabled Parity Check None...
  • Page 146 Parameter Factory Default Remark Codabar Codabar Enabled Parity Check None Check Digit Do not transmit Start/Stop Character Do not transmit Start/Stop Character Format ABCD/ABCD Maximum Length Minimum Length Code 93 Code 93 Enabled Parity Check Enabled Check Digit Do not transmit Maximum Length Minimum Length GS1 Databar...
  • Page 147 Parameter Factory Default Remark MSI-Plessey MSI-Plessey Disabled Parity Check One check digit, MOD10 Check Digit Do not transmit Maximum Length Minimum Length PDF 417 PDF 417 Enabled Maximum Length 2710 Minimum Length QR Code QR Code Enabled Micro QR Enabled Maximum Length 7089 Minimum Length...

  • Page 148: Aim Id Table

    AIM ID Table Symbology AIM ID Remark Standard EAN-13 EAN-13 EAN-13 + 2/5-Digit Add-On Code Standard EAN-8 EAN-8 ]E4…]E1… EAN-8 + 2-Digit Add-On Code ]E4…]E2… EAN-8 + 5-Digit Add-On Code Standard UPC-E UPC-E UPC-E + 2/5-Digit Add-On Code Standard UPC-A UPC-A UPC-A + 2/5-Digit Add-On Code Code 128...
  • Page 149 Symbology AIM ID Remark Standard Codabar Codabar Transmit check digit after parity check Do not transmit check digit after parity check Code 93 Standard Code 93 One check digit MOD11; transmit check digit Two check digits, MOD11/MOD11; transmit check digit Code 11 Do not transmit check digit after parity check No parity check...
  • Page 150 Symbology AIM ID Remark 2005 version, ECI excluded 2005 version, ECI included QR Code 2005, ECI excluded, FNC1 is the 1st character after the start character QR Code QR Code 2005, ECI included, FNC1 is the 1st character after the start character QR Code 2005,ECI excluded,FNC1 is the 2nd character after the start character...

  • Page 151: Code Id Table

    Code ID Table Symbology Code ID Code 128 UCC/EAN-128 AIM-128 EAN-8 EAN-13 ISSN ISBN UPC-E UPC-A Interleaved 2 of 5 ITF-6 ITF-14 Matrix 2 of 5 Industrial 2 of 5 Standard 2 of 5 Code 39 Codabar Code 93 Code 11 Plessey MSI-Plessey GS1 Databar...

  • Page 152: Ascii Table

    ASCII Table Char (Null char.) (Start of Header) (Start of Text) (End of Text) (End of Transmission) (Enquiry) (Acknowledgment) (Bell) (Backspace) (Horizontal Tab) (Line Feed) (Vertical Tab) (Form Feed) (Carriage Return) (Shift Out) (Shift In) (Data Link Escape) (XON) (Device Control 1) (Device Control 2) (XOFF) (Device Control 3) (Device Control 4)
  • Page 153 Char (Request to Send) (Unit Separator) (Space) (Exclamation Mark) " (Double Quote) (Number Sign) (Dollar Sign) (Percent) & (Ampersand) (Single Quote) (Right / Closing Parenthesis) (Right / Closing Parenthesis) (Asterisk) (Plus) (Comma) (Minus / Dash) (Dot) (Forward Slash) (Colon) (Semi-colon) <...
  • Page 154 Char > (Greater Than) (Question Mark) (AT Symbol) (Left / Opening Bracket) (Back Slash) (Right / Closing Bracket)
  • Page 155 Char (Caret / Circumflex) (Underscore) (Grave Accent) (Left/ Opening Brace) (Vertical Bar) (Right/Closing Brace) (Tilde) (Delete)
  • Page 156 TEL： +31 （0） 345 87 00 33 FAX： +31 （0） 345 87 00 39 Email： sales@newland-id.com WEB： www.newland-id.com Tech Support： tech-support@newland-id.com Newland North America Inc. /北美新大陆有限公司 Address： 46559 Fremont Blvd.， Fremont， CA 94538， TEL： 510 490 3888 Fax： 510 490 3887 Email： info@newlandna.com WEB：...

Table of Contents

Save PDF
