Add New Access Rule - Allnet ALL-VPN10 User Manual

Delete：
Add New Rule：
Restore to Default
Rule：
10.2.1

Add New Access Rule

Action：
Service：
Service Management：
Log：
Source Interface：
Source IP：
Remove the item.
Create a new network access rule
Restore all settings to the default values and delete all the self-defined settings.
Allow: Permits the pass of packets compliant with this control rule
Deny: Prevents the pass of packets not compliant with this control rule
From the drop-down menu, select the service that users grant or do not give
permission.
If the service that users wish to manage does not exist in the drop-down menu,
press – Service Management to add the new service.
From the pop-up window, enter a service name and communications protocol
and port, and then click the "Add to list" button to add the new service.
No Log： There will be no log record.
Create Log when matched： Event will be recorded in the log.
Select the source port whether users are permitted or not (for example: LAN,
WAN1, WAN2 or Any). Select from the drop-down menu.
Select the source IP range (for example: Any, Single, Range, or preset IP group
name). If Single or Range is selected, please enter a single IP address or an IP
