Allnet ALL-VPN10 User Manual page 127

ALL-VPN10 VPN/Firewall WLAN-N WAN Router
settings.
(4) Dynamic IP + Domain Name(FQDN) Authentication:
If users use dynamic IP address to connect to the device, users may select
this option to link to VPN. If the remote VPN gateway requires connection
to the device for VPN connection, this device will start authentication and
respond to this VPN tunnel connection; if users select this option to link
to VPN, please enter the domain name.
(5) Dynamic IP + E-mail Addr. (USER FQDN) Authentication.
If users use dynamic IP address to connect to the device, users may select
this option to connect to VPN without entering IP address. When VPN
Gateway requires for VPN connection, the device will start authentication
and respond to VPN tunnel connection; if users select this option to link
to VPN, enter E-Mail address to the empty field for E-Mail authentication.
This option allows users to set the local VPN connection access type. The
Local Security Group Type：
following offers a few items for local settings. Please select and set
appropriate parameters:
1. IP address
This option allows the only IP address which is entered to build the VPN
tunnel.
Reference: When this VPN tunnel is connected, computers with the IP
© ALLNET GmbH München 2013 - All rights reserved 127
