Allnet ALL1692 Quick Setup Manual

Powerline network

Advertisement

Quick Links

ALL1692
Powerline Network
ALL1692
Powerline Network
Instant Networks for Internet Access...and More!
Solution for SOHO, S
© 2005 . All rights reserved.
MALL

QUICK SETUP GUIDE

ETHERNET BRIDGE ALL1692
O
H
FFICE AND
OME
for
Page 1
O
FFICE

Advertisement

loading
Need help?

Need help?

Do you have a question about the ALL1692 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Allnet ALL1692

  • Page 1: Quick Setup Guide

    ALL1692 Powerline Network ALL1692 Powerline Network Instant Networks for Internet Access…and More! Solution for SOHO, S MALL FFICE AND FFICE QUICK SETUP GUIDE ETHERNET BRIDGE ALL1692 © 2005 . All rights reserved. Page 1...
  • Page 2 ALL1692 Powerline Network © 2005 . All rights reserved. Page 2...
  • Page 3 ALL1692 Powerline Network REFACE This document describes installation of the ALL1692 Network products. Please read this document before installing the product. O THE NSTALLER This publication contains the following sections: Important safety instructions The first thing you need to know before you begin to install...
  • Page 4: Important Safety Instructions

    Because the ALL1692 sends data over the powerline, it is recommended that you plug directly into a power outlet. Do not plug the device into a UPS or power strip with surge protection. The ALL1692 has its own power filter for protection against surges.
  • Page 5 Pentium® 166 MHz processor, equivalent or higher Resource on your PC At least one free Ethernet port for ALL1692 2. Your PC must not be configured for another network. This means that: No network clients except for Microsoft Network*, Client for Netware* Networks, or Microsoft Family...
  • Page 6 ALL1692 Powerline Network 5. Familiarize yourself with the ALL1692 device connections: 6. Limitation of the PLC device: To meet the safety regulation, the longest distance between powerline carrier devices will be limited at 100 meter and for in-house use only.. More than 100 meter will cause the signal reduction or data loss.
  • Page 7 ALL1692 Powerline Network RODUCT NSTALLATION UIDE Product installation guide Important: Do not plug the device into a power strip or surge protector because these devices may consist of filter and impair signal. Also avoid plugging the device right next to noisy sources such as cell phone charger, Halogen light, noisy desktop computer, vacuum cleaner, etc.
  • Page 8: Specification

    ALL1692 Powerline Network PECIFICATION Specification Items Description Line Rate 28Mbps Ftp Data Rate Up to 8Mbps effective throughput Frequency Band 4.3~20.9 MHz Access Methods CSMA/CA 4 Levels Modulation OFDM / 64 QAM Port One Ethernet port Standards IEEE 802.3, IEEE 802.3U, HomePlug 1.0.1...
