Allnet ALL-VPN10 User Manual page 141

is not in the list, we recommend that users use "Service Port Management" to add or remove ports, as follows：
Service Name：
Protocol：
Port Range：
Add to list：
Delete selected item：
Apply：
Cancel：
Close：
Input the name of the service port users want to activate on the list, such as
E-donkey, etc.
To select whether a service port is TCP or UDP.
To activate this function, input the range of the service port locations users
want to activate such as 500~500 or 2300~2310, etc.
Add the service to the service list. It supports up to 100 rules.
To remove the selected services.
Click the "Apply" button to save the modification.
Click the "Cancel" button to cancel the modification. This only works before
"Apply" is clicked.
Quit this configuration window.
