7.0 Control System
7.0 R-net control system information
An alternative control system called R-net is available as
an option for the wheelchair .
The R-net system has extended options and is suitable
for individuals with complex needs or when there
is a preference for screen based menu options and
information displays.
The R-net control system offers simple, effective
solutions to many situations, thereby enhancing the
lifestyle and independence of the user.
The operation of the R-net wheelchair control system is
simple and easy to understand. Both the R-net and VR2
control systems incorporates state-of-the-art electronics,
the result of many years of research, to provide you with
ease of use and a very high level of safety.
Because of the comprehensive nature of the R-net
control system, a separate R-net Owner's Manual is
supplied whenever this system is fitted.
Please refer to the R-net Owner's Manual for
details of R-net hand control functions.
40
SALSA M
2
Mini
7.1 VR2 control system information
On/off button:
The on/off button applies power to the control system
electronics, which in turn supply power to the wheelchairs
motors.
CAUTION!
Do not use the on/off button to stop the wheelchair
unless there is an emergency. (If you do you may shorten
the life of the wheelchair drive components).
Battery gauge:
The battery gauge shows you that the wheelchair is
switched on. It also indicates the status of the wheelchair
. Refer to chapter 8.
Locking/unlocking the wheelchair :
The VR2 control system can be locked to prevent
unauthorised use. The locking method is via a sequence
of key presses and joystick movements as detailed
below.
To lock the wheelchair :
•
While the control system is switched on, depress and
hold the on/off button.
•
After 1 second the control system will beep. Now
release the on/off button.
•
Deflect the joystick forwards until the control system
beeps.
•
Deflect the joystick in reverse until the control system
beeps.
•
Release the joystick, there will be a long beep
•
The wheelchair is now locked.
To unlock the wheelchair :
•
Use the on/off button to switch the control system on.
The maximum speed/profile indicator will be rippling
up and down.
•
Deflect the joystick forwards until the control system
beeps.
•
Deflect the joystick in reverse until the control system
beeps.
•
Release the joystick, there will be a long beep.
•
The wheelchair is now unlocked.
Rev.1.0
