9.0 Controller Mounts
9.1 General warnings:
WARNINGS!
•
Do not replace the joystick knob with any
unauthorised item. It may cause hazardous operation
and loss of control of the wheelchair.
•
It is important that the joystick boot is replaced if it is
torn or brittle; failure to do so could cause substance
damage to the controller and unexpected movement
of the wheelchair.
•
Ensure that you always have comfortable access
to the controls whilst the wheelchair is moving and
make sure that the controller is fixed securely to the
wheelchair.
9.2 Attendant control:
WARNINGS!
•
Ensure that you set the speed of the attendant control
to a speed that you can comfortably follow.
•
Always turn off the power to the controller when
leaving the user in the wheelchair. (Fig.9.1).
Attendant control
Rev.1.0
9.3 Parallel swing-away control:
WARNINGS!
•
Before adjusting the swing-away arm, switch off the
controller to avoid accidental displacement of the
joystick which would cause unwanted movement of
your wheelchair .
•
Keep your fingers and clothing, etc. clear while
operating the swing-away mechanism.
•
Be aware that the width of your wheelchair has
increased if the swing-away arm is out and you may
not get between certain obstacles.
•
Do not hang any items on or over the parallel swing-
away remote assembly as this could damage the
swing-away mechanism.
•
When transferring to and from the wheelchair do not
use the remote as a means of support.
•
Ensure the power is switched off while adjusting the
parallel swing-away arm.
•
Only operate the wheelchair at low manoeuvring
speed when the parallel swing-away is in use,
(Fig.9.2).
R-net Control
Please refer to your R-net Owner's Manual for
details.
Fig.9.1
Parallel swing-away control
Fig.9.2
47
SALSA M
2
Mini
