6.13 JAY backrests
Fig. 6.27
The standard backrest assembly will allow the fitting of a
JAY backrest, which is available as an optional extra.
6.14 Headrest
To fit the Standard headrest, fit the location bracket to
the push handles, using the screws and nuts supplied,
ensuring that they are fully tightened.
To fit the Rehab headrest, fit the location bracket to the
backrest bracket, using the screws and nuts supplied,
ensuring that they are fully tightened.
Adjusting the Headrest (All).
The headrest height is changed by loosening the
adjustment knob and sliding the inner vertical tube to the
desired position and tightening the knob. The headrest
to seat depth is adjusted by loosening the 6mm Allen
screws and moving the hinge to the desired position
and then tightening the screws securely. To adjust the
headrest angle, loosen the screws at the headrest
upholstery, position the headrest as required and tighten
the screws securely. (Fig.6.27).
37
Rev.1.0
